solar panel controller schematic MPPT 96V 50A
GENERAL DESCRIPTION:
SC-MH DC96V high-end series ranked the first among MPPT solar charge controllers. Advantages include high conversion efficiency, system automatic recognition, wide range of PV input, professional PC monitoring software etc.. This is the most classical version of MPPT solar charge controller.
PRODUCT FEATURES
____________________________________________________________________________________________
|
Max PV Input DC 300V |
| SCP MPPT SOLAR CHAGE CONTROLLER |
| Peak Efficiency Up to 99% |
| Maximum power point track |
|
Charging Method MPPT |
| 60A SOLAR CHARGER |
|
Software Online-Upgrade |
| CE Approved PV CHARGER |
| Unlimited PARALLEL |
BATTERY OPTIONS
_____________________________________________________________________________________________
+ |
+ | + | + | |||||
Sealed Lead |
GEL Battery | Vented Battery |
Ni-Cd Battery |
|||||
- |
- | - |
- |
(Compatible with other types of batteries as well!!! )
PRODUCT PARAMETERS
_____________________________________________________________________________________________
SC-MH MPPT Solar Charge Controller DC96V High-End Series | |||||||
SC-MH (DC96V) |
20A | 25A | 30A | 40A | 50A | 60A | |
Charge Mode |
MPPT (maximum power point tracking) |
||||||
|
Charge Method
|
3 stages: constant current, constant voltage, floating charge |
||||||
MPPT Efficiency |
96V System |
≥96.5%,≤99% |
|||||
INPUT CHARACTERISTICS | |||||||
MPPT working voltage range |
96V System |
DC110V~DC220V |
|||||
Max. PV Voltage |
96V System |
DC300V |
|||||
Max. PV Power |
96V System |
2240W |
2750W |
3300W |
4400W |
5500W |
6720W |
CHARGE CHARACTERISTICS | |||||||
Battery Type (Default Gel Battery) |
96V System |
Sealed lead acid, Vented, Gel, NiCd battery |
|||||
Rated Input Current |
96V System |
20A |
25A |
30A |
40A |
50A |
60A |
MECHANICAL CHARACTERISTICS | |||||||
Size D x W x H(mm) |
155*308*86 |
||||||
N.W.(kgs) |
4 |
||||||
G.W.(kgs) |
4.5 |
||||||
The specification is only for reference, subject to change without without prior notice! | |||||||
PRODUCT PHOTOS
___________________________________________________________________________________________________
Founded in 2009, Foshan SC Power Technology Ltd. is a National Key Support High-Tech Enterprise which integrated with R&D, production and marketing of Solar Inverter, Solar MPPT Controller, Hybrid Inverter (inverter with controller) and related solar power system products.
OUR ADVANTAGES:
Rapid growing industry
We are factory
High spirit team
Master core technology
Fast response and quality service
Full set of self-developing tools convenient to modify custom settings
Full team support for sales and technical services
PRODUCTION ABILITY:
5000sets/month ( Inverter/Hybrid Inverter)
10000sets/month (MPPT Solar Charge Controller)
R & D:
OEM / ODM acceptable
Warmly welcome to inquiry & place orders and wish we have a win-win business cooperation.
FACTORY BUILDING & OFFICE BUILDING
FACTORY & OFFICE INNER VIEW
Q1:Did your inverter include charger?
A1:Yes.
Q2: What's the different between inverter and hybrid inverter?
A2: Hybrid built-in MPPT solar charge controller,but inverter not.
Q3:What payment terms do you offer?
A3:T/T,western union,LC,paypal
Q4: What is the default product warranty
A4: One year .
Q5:Can you help on arrange the shipment?
A5:Yes,please offer your nearest destination port name to our customer service assistant.
Q6:I need OEM product?
A6:it's welcome.please show us your idea.
