YWF 4E-450mm series Out-rotor Axial Fan

The model described

      YWF   4    E --450  S

     1      2     3    4    5

       1.  Fan Type: YWF-external rotor axial fan
                                         2.  Motor pole: 2 ---  2-pole electrode 4 ---4-pole electrode

                             3. Motor voltage: E --- Three-phase  D ---  single-phase
                                 4.   Blade diameter: 450 --- The blades diameter of 450mm

                                                           5. Wind: S --- Suction     B ---Blowing

YWF series fan is widely used in ventilation and refrigeration industry, compact structure, easy installation, energy efficient
