Specifications
1.vga splitter 1 to 22.Support 1920x1200p
3.Extend 300m by single UTP cable
4.Splitter with audio
5.Welcom OEM
high quality vga splitter 1 to 2 with audio
1. Description
This vga splitter 1 to 2 with Audio is an ideal device for local displaying and remote viewing. It combines split function and extension function. It distributes the input of the VGA signal and audio signal into the local and remote outputs simultaneously. Receiver by Cat5 x1 works with the Sender as a full functional module by receiving the distributed signal from the sender and transmitting to display. Only by the most inexpensive UTP cable with cross stand nside, the full functional module extend the VGA display max up to 300 meters.
It offers solutions for VGA retail and show site and Projector factory, noise, space and security concerns, data center control, information distribution, conference room presentation, school and corporate training environments.
2.Features
This vga splitter 1 to 2 has many features that enable it to perform in a superior manner. Among those features you will find:
* Extend VGA video and stereo audio signal max up to 300m over one UTP cable with cross stand inside
* Adjusting GAIN and PEAK to adapt for the different length of UTP cable.
GAIN: Brightness adjustment.
PEAK: Skew adjustment.
* Supports resolution max up to 1920x1200.
* Dual output at local unit: 1 x VGA output for local site, plus 1 x UTP output for remote site.
* Work with monitors projec tors, HDTV, and flat panels.
3.Specifications
| Input connector | VGA(Female 15pin), Stereo Audio |
| Output connector | VGA(Female 15pin), Stereo Audio,1xRJ45 |
| Vertical Frequency Range | 60/75/85Hz |
| Resolutions(PC) | 640X480 800X600 1024X768 1280X720 1280X768 1280X960 280X1024
1600X900 1600X1200 1920X1080
1920X1200
|
| Power Supply for VGA UTP Extender 1X1 Splitter
|
5V@2A, max 5W |
| Power Supply for Receiver | 5V@2A, max 5W |
| Operating Temperature | 0°C to +70°C |
| Operating Humidity | 10% to 85 % RH (no condensation) |
| Storage Humidity | 5% to 90 % RH (no condensation |
| Power consumption (Max) | 5W |
| External Power Supply | No power needed |
| User Manual | English Version |
| Converter unit | FCC,CE |
| AC power adapter | US standard , UK standard and so on |
As a specialized independent supplier of HDMI products, Protech Electronics & Technology Limited focuses on high quality image process technology and application design,owns perfect production lines and innovates on technical route continually to provide the best solutions for home media, especially for HD source connection,experienced OEM, ODM production.
We are member of HDMI Associate and HDCP Associate, vga splitter 1 to 2 have CE,FCC,RoSH Certificate, so that our products can be export to most of country.We are warmly welcome other companys to be our commission agent.
