Specifications
1.5 port HDMI switcher2.support 4Kx2K 3D
3.IR remote control
4.Support HDMI1.4V
5.CE,FCC,ROHS,HDMI
5 into 1 HDMI switcher + IR Remote support 4kx2k resolution
Introduction
This HDMI Switcher routes high definition video (in multiple resolutions up to 4K X 2K) and digital audio from any one of the five sources to display unit.The output sends the high definition audio/video signals to a high definition display. This kind of the HDMI Amplifier Switcher not only has the key-press-switching function, but also has the IR remote control and intelligent function.
Features
* Multifunctional on switching : intelligent or mechanical
* IR extender receiver (included)
* IR remote (included)
* Support HDMI1.4b, HDCP pass-through.
* Support highest video resolution 4k x 2k @30 1080p and 3D.
* Support 300MHz/3.0Gbps per channel bandwidth
* Support 12bit per channel deep color,36 bit Total.
* Support uncompressed audio such as LPCM (Linear Pulse Code Modulation).
* Support compressed audio such as DTS Digital, Dolby Digital
(including DTS-HD and Dolby True HD).
SPECIFICATIONS
Input DDC Signal |
5 volts p-p (TTL) |
Maximum Single Link Range |
4k x 2k |
Output Video |
HDMI 1.4b |
Vertical Frequency Range |
30/50/60Hz |
Video Amplifier Bandwidth |
3.0Gbps/300MHz |
Interlaced(50&60Hz) |
480i,576i,1080i |
Progressive(50&60Hz) |
480p,576p,720p,1080p,4k x 2k |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0 °C to +70°C |
Operating Humidity |
10% to 85 % RH (no condensation) |
Storage Temperature |
-10°C to +80°C |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power consumption (Max) |
5W |
User Manual |
English Version |
Intelligent function
1) When supplied with power, this switcher will select the power-on source device depending on the sequence automatically (input1>input2>input3>input4>input5)
2) Once the source device is turned on or plugged in (should stay power-on mode), the switcher will automatically select this source.
3)Once the source device is turned off or plugged out, the switcher will automatically select the next power-on source depending on the sequence automatically (input1>input2>input3>input4>input5 )
Note:
1) When the source devices are on the stand-by mode, its power supply should be turned off, otherwise this switcher can not meet intelligent function.
2) When plugged in or out, this switcher is completely intelligent.
Package Contents
1) Main unit
2) IR receiver
3) Remote control
4) User Manual
