China manufacturer SDI to HDMI Converter HDMI switch to 3G HD SD SDI Signals Supports 1080P60Hz
Item: SDI to HDMI Converter, 3G/SD/HDSDI to HDMI Converter, SDI to HDMI Converter with Upscaler, SDI to SDI+HDMI Converter
1.0 Introduction
The SDI to HDMI converter enables you to turn a 3G/SD/HDSDI video signal into an HDMI video output and an
SDI display.
The device comes with a scaler that will allow you to adjust the output signal to a resolution (720p/1080p) that is compatible with your HDMI-enabled display.
The converter features a built in SDI daisy chain port, giving you the ability to further extend the SDI source
infinitely, for large scale SDI video broadcasting distribution.
To ensure you maintain perfect high-definition video quality, the SDI HDMI converter features supports
resolutions up to 1080p, allowing you to convert SDI to HDMI without sacrificing video quality.
For hassle-free installation, the SDI to HDMI converter offers a plug-and-play solution that includes pre-installed mounting brackets and requires no software or driver installation.
2.0 Features
* Input: 1 x SDI;
* Output: 1 x SDI; 1 x HDMI;
* Built-in scaler allows user to adjust the output signal to a resolution (720p/1080p) that is compatible
with your HDMI-enabled display.
* No need to install drivers, portable, flexible, plug and play.
* Auto-detect resolution of HD-SDI, SD-SDI and 3G-SDI.
* Data transfer rate: 270Mb/s,1.485Gb/s, 2.97 Gb/s.
* Coaxial cable impedance: 75Ω
* Output to an HDMI Display for 15m (50 feet) max, SDI display for 100m (328 feet) max and continue your SDI run up infinitely using the daisy chain port
3.0 Specifications
Input Signal |
SDI Signal (HD-SDI, SD-SDI and 3G-SDI) |
Output Signal |
HDMI x1,SDI x1 |
SDI Data Transfer Rate |
270Mb/s, 1.485Gb/s, 2.97Gb/s |
SDI Input Resolution |
480i@60Hz/576i@50Hz/720P@50Hz/720P@60Hz, 1080i@50Hz/1080i@60Hz; 1080P@24Hz@25Hz@30Hz@50Hz@60Hz |
SDI Output Resolution |
480i@60Hz/576i@50Hz/720P@50Hz/720P@60Hz, 1080i@50Hz/1080i@60Hz; 1080P@24Hz@25Hz@30Hz@50Hz@60Hz |
HDMI Output |
720P@60Hz,1080P@60Hz |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0C to +50C |
Operating Humidity |
10% to 85 % RH (no condensation) |
Storage Temperature |
-10C to +80C |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power Supply |
5V DC |
Power Consumption (Max) |
5W |
Converter Unit Cert. |
FCC,CE, |
User Manual |
English Version |
4.0 Package Contents
1) Main unit SDI To HDMI Converter
2) 5V DC Power Adapter
3) User Manual
Packages available
1. Neutral gift box or custom design beautiful in appearance
2. Bubble pack reduce cost to least
Payment and Shipping
1) We are member of HDMI Association(can be found on HDMI official website ), you won't have any import problem when work with us.
2) We are specialize in HDMI Accessory for more than 7 years, have professional R&D department, and QC department.
3) With possession of complete SMT machines, we can better control goods quality and lead time.
4) 7 years exporting experience, we can do perfect OEM order.
SMT (Surface Mounted Technology) Machines for pasting PCBA
Protech Electronics &Technology Limited, branded as Protech, founded in 2008, located at No.6 Baofu road, Baolai Industry Park, Pinghu Town, Longgang District, Shenzhen, is a market leading manufacturer of HDMI products. Over the years, Protech has gained experience and knowledge in electronic business, market development and the HDMI industry. We have always found pride in our solid quality control, exceptional products, immediate availability and continual product development, a keen sense of what distributors and their customers need to build and grow.
Protech always persists with high quality, it is operated strictly according to the standard operating procedures and rules with the rich and applicable laboratory equipment, high quality so that to makes every client satisfactory. You can find that we have a comprehensive inspection system on the products upon visiting our factory: full inspection on raw material, full inspection on PCB, full inspection on semi-finished products, full inspection on finished products, full inspection and random inspection before packing, random inspection before shipment. This is how we assure the quality of our goods.
Protech is committed to the green products and has the comprehensive RoHS,CE,FCC system. We are also one of the HDMI Adopter manufacturers .
