Help Center3G SDI to VGA +SDI Converter With 3.5MM 1080P SDI Input VGA/SDI Output
Related Products
-
Wholesale 2016 Newest Price for SDI to HDMI Converter SDI or HD-SDI to HDMIUS$ 21.6 - 23.5MOQ: 50 Pieces -
Hot Sell HDMI to Sdi Converter Hdmi Input X1 Sdi OutputX2US$ 30.9 - 33.9MOQ: 50 Pieces
-
Hot Sell 3G/SD/HD-SDI to AV Video Output and SDI Display ScalerUS$ 33.3 - 47.7MOQ: 50 Pieces
-
hd Sdi to Hdmi Converter 1080p SDI Converter Support 100meter SDI Signal With USB CableUS$ 1 - 29MOQ: 50 Units
-
3G/SD/HD-SDI to VGA Converter 2.970 Gbit/s Sdi to VGA Support 480i &720p&1080p ResolutionUS$ 1 - 87MOQ: 50 Units
3G SDI to VGA Converter
1.0 Introduction
This product designed to convert SD,HD and 3G SDI signal to analog VGA signal.
2.0 Features
- SDI interface operates at bit rates:2.970Gbit/s 2.970/1.001Gbit/s,1.485Gbit/s,1.485/1.001Gbit/s and 270Mb/s
- Auto-detection of connected SDI sources resolution.
-
Support SDI input resolution:
- 480i/60Hz 576i/50Hz
- 720P/50Hz 720P/60Hz
- 1080i/50Hz 1080i/60Hz
- 1080P/50Hz 1080p/60Hz
-
Support VGA output resolution:
- 800×600/60Hz
- 1024×768/60Hz
- 1280×720/60Hz
- 1280×1024/60Hz
- 1360×768/60Hz
- 1440×900/60Hz
- 1600×1200/60Hz
- 1920×1080/60Hz
- Input port: SDI in, DC in
- Output port :SDI loop out, Stereo audio
3.0 Specifications
Signal Inputs |
SDI Signal (HD-SDI, SD-SDI and 3G-SDI) |
Output Video |
VGA Signal |
SDI date rate |
270Mb/s, 1.485Gb/s, 2.97Gb/s |
SDI input resolution |
480i/60Hz 576i/50Hz 720P/50Hz 720P/60Hz 1080i/50Hz 1080i/60Hz 1080P/50 1080p/60Hz |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0℃ to +50℃ |
Operating Humidity |
10% to 85 % RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power Supply |
5V |
Power consumption (Max) |
5W |
Converter Unit Cert. |
FCC,CE, |
User Manual |
English Version |
Note: Specifications are subject to change without notice.
4.0 Package Contents
- Main unit
- 5V DC Power Supply
- User Manual
Certificates
Certifications: CE, FCC, HDMI Adopter, REACH, RoHS
