Hdmi Matrix Switch 4x2 With Optical or Analog Audio Out PET0402A
Negotiable
MOQ: 50 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Brand Name:
protech
Model Number:
PET0402A
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Hdmi Switch Splitter 4x4 Extender Over Hdmi Cable or Cat5e Cable PET0404ENegotiableMOQ: 20 Pieces -
4x4 Hdmi Switch Splitter PET0404ENegotiableMOQ: 20 Pieces
-
Hdmi Switch Splitter 4x2 AUDIO COAX SPDIF Out PET0402ANegotiableMOQ: 50 Pieces
-
4x2 Hdmi Matrix With Optical or Analog Audio Out PET0402ANegotiableMOQ: 50 Pieces
-
Digital Video Hdmi Matrix 4 Input 2 Output With Audio Out PET0402ANegotiableMOQ: 50 Pieces
Brand Name
protech
Model Number
PET0402A
Place of Origin
Guangdong, China
2 input 4 output hdmi switch splitter PET0402A
Item: hdmi switch splitter 4 in 2 out , hdmi matrix 4x2 , hdmi switch 4 in 2 out , 4 in 2 out hdmi switch splitter
Introduction
The HDMI SWITCH SPLITTER Matrix routes high definition video in multiple resolutions up to 1080p plus multichannel digital audio from any of the four HDMI sources to two displays.
It eliminates the needing of disconnects and reconnects sources to a display equipped with one input. It works with HD-DVD players, Blue Ray DVD, PS3, and satellite set top boxes that connect to two HDMI displays.
Every source is accessible at all times by any display by selecting it with an IR remote.
2.Features
* Supports audio output simultaneously: Stereo, Toslink and Coaxial
* It can be selected using Remote control for output A. 5.1CH can be sent by Toslink and Coaxial
* Supports 12bit per channel (36bit all channel) deep color.
* Supports uncompressed audio such as LPCM.
* Supports compressed audio such as DTS Digital, Dolby Digital
* Support 3D
3.Specifications
| Input Signal | HDMI Signal |
| Output Video | HDMI / AUDIO / COAX / SPDIF Signal |
| Vertical Frequency Range | 50/60Hz |
| Video Amplifier Bandwidth | 2.5Gbps/250MHz |
| Interlaced(50&60Hz) | 480i,576i,1080i |
| Progressive(50&60Hz) | 480p,576p,720p,1080p |
| Operating Temperature | 0°C to +70°C |
| Operating Humidity | 10% to 85 % RH (no condensation) |
| Storage Humidity | 5% to 90 % RH (no condensation |
| External Power Supply | 5V DC@2A |
| Power consumption (Max) | 8W |
| User Manual | English Version |
Package : Neutral gift box,color box or custom design.
Foam package in this way , reduce cost to least
