All SUS304 Commercial Meat Bowl Chopper Machine
Woring Principle:
The meat bowl r chopper machineiadopts highspeed knife cutting principle,cut meat as well as auxiliary material into meat filling or meat paste in short time,it can also mix meat,auxiliary material and water into uniform emulsion.The reasonable design of knife speed,pot speed,clearance between knifepoint and pot makes each part achieve the best combination.In such way,the finished meat product has the characteristics of good fineness,low temperature rise,short cutting time,moreover,the processed sausage product flexibility and fineness degree is greatly enhanced because of emulsification.
The meat bowl cutter can also cut various vegetables,fruits as well as other material into block, Granule and paste.
Features:
1.All of the machine is made of food grade SUS304 (bowl,pot,rack,sheel etcd.),the structure is compact and beautiful,easy to clean,it is in accordance with food hygiene standards
2.The main parts are processed by CNC machining center to ensure accuracy.
3.The knives are made of 9CrSi,sharp and durable,smooth running in high speed.
4.Sweden imported SKF bearing,the imported dual-bearing spindle tandem installation,ensure knife shaft group has good concentricity.
5.The good quality copper core motors comply with the European standard , strong anti-overload.
6.Maximum speed can reach 4500 rpm,,which can greatly improve the emulsifying effect , so that the processed meat product production rate is higher .
7.The reasonable design of knife speed,pot speed,clearance between knifepoint
and pot makes each part achieve the best combination.In such way,the finished meat product has the characteristics of good fineness,low temperature rise,short cutting time.
8.Frequency conversion technology can also be adopted on request,high range
knife speed adjustment,high efficiency and energy saving
Model |
ZB-20 |
ZB-40 |
ZB-80 |
ZB-80 (frequency conversion) |
ZB-125 |
ZB-125 (frequency conversion) |
Volume(L) |
20 |
40 |
80 |
80 |
125 |
125 |
|
Capacity (kg/batch) |
15 |
30 |
60 |
60 |
100 |
100 |
Power (Kw) |
1.85 |
5.5 |
13.17 |
13.17 |
21.85 |
21.85 |
Voltage(V) |
380 |
380 |
380 |
380 |
380 |
380 |
|
Knife Quantity (pcs) |
3 |
3 |
6 |
6 |
6 |
6 |
|
Knife Speed (rmp) |
1500/3000 |
1500/3000 |
1500/3300 |
stepless speed regulation |
1800/3500 |
stepless speed regulation |
|
Pot Speed (rmp) |
16 |
12 |
8/16 |
8/16 |
10/16 |
10/16 |
|
Dimension (mm) |
770*650* 980mm |
1150*750* 1200mm |
1400*820* 1300mm |
1400*820 *1300mm |
2090*1200 *1450mm |
2090*1200* 1450mm |
