Emulex LightPulse 4Gb Singl-Port Fiber Channel PCIe Host Bus Adapter LPe11000

Emulex LightPulse 4Gb Singl-Port Fiber Channel PCIe Host Bus Adapter LPe11000 thumbnail-1
Emulex LightPulse 4Gb Singl-Port Fiber Channel PCIe Host Bus Adapter LPe11000 photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Products Status:
Stock
Application:
Server
Type:
Wired
Contact Supplier Request Quote Chat Now
Shenzhen Hisco Technology Limited
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen or Hong kong
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Products Status Stock
Application Server
Type Wired
Kind Internal
Transmission Rate Other, 4 Gbps
Interface Type PCI Express
Certification UL CE
Brand Name Emulex
Model Number LPe11000
Place of Origin China

Specifications

1.LPe11000
2.Full New and Original
3.Good Price from China General Agency
4.It is in Stock
5.Global Coverage

Emulex LightPulse LPe11000 4Gb Singl-Port Fiber Channel PCIe Host Bus Adapter



Product Descriptions



Ports/Channels    2 x LC Fibre Channel
Data Transfer Rate    4.25 Gbps Fibre Channel
Connectivity Media    Multi-mode Fiber
Host Interface    PCI Express x4
Form Factor    Plug-in Card
Height    2.5"
Width    6.6"



Extended specifications




Technical Information

Ports/Channels    2 x LC Fibre Channel
Host Interface    PCI Express x4



Media & Performance

Connectivity Media    Multi-mode Fiber
Data Transfer Rate    4.25 Gbps Fibre Channel



Management & Protocols

Protocols FC-AL-2
FC-FLA
FC-FS
FC-GS-4
FC-PH3
FC-PI-2
FC-PLDA
FC-Tape
FC-FCP2
FC-IP



Physical Characteristics

Height 2.5"
Form Factor Plug-in Card
Width

6.6"



Standards

  • ANSI Fibre Channel: FC-PH-3, FC-PI-2, FC-FS, FC-AL-2, FC-GS-4, FC-FLA, FC-SP, FC-PLDA, FC-TAPE, FCP-2, and RFC 2625 (IP over FC)
  • PCI Express base spec 1.0a
  • PCI Express card electromechanical spec 1.0a
  • Fibre Channel class 2 and 3
  • PHP hot plug-hot swap
Architecture
  • Single-channel
  • 4Gb/s, 2Gb/s or 1Gb/s FC Link speeds automatically detected
  • Integrated data buffer and code space memory
 Comprehensive OS Support
  • Widws, Linux, NetWare, Solaris, VMware, HP-UX
  • Additional support is available from OEMs and partners

Hardware Environments
  • PowerPC®, SPARC®, x86, x64 and Intel® Itanium® 64-bit processor family
 Optical
  • Data rates: 1.0625, 2.125 and 4.25Gb/s (auto-detected)
  • Optics: Short wave lasers with LC type connector
  • Cable: 50/125 microns, up to 150 meters at 4Gb/s 62.5/125 microns, up to 70 meters at 4Gb/s
 Physical Dimensions
  • Short, low profile MD2 form factor card
  • 167.64mm x 64.42mm (6.60” x 2.54”)
  • Standard bracket (low profile available)
 Power & Environmental Requirements
  • Volts: +3.3
  • Operating temperature: 0° to 55°C (32° to 131°F)
  • Airflow required: 100 lf/m
  • Storage temperature: -40° to 70°C (-40° to 158°F)
  • Relative humidity: 5% to 95% non-condensing
 Agency Approvals
  • Class 1 Laser Product per DHHS 21CFR (J) and EN60825-1
  • UL recognized to UL 60950-1
  • CUR recognized to CSA22.2, No. 60950-1-03
  • TUV certified to EN60950-1
  • FCC rules, Part 15, Class A
  • ICES-003, Class A
  • EMC Directive 2004/108/EEC (CE Mark)
    • EN55022, Class A
    • EN55024
  • Australian EMC Framework (C-Tick Mark)VCCI, Class A
    • AS/NZS CISPR22, Class A
  • MIC (Korea), Class A
  • BSMI (Taiwan), Class A
  • RoHS Compliant (Directive 2002/95/EC) for environmental requirements
Additional Features
  • Emulex LightPulse technology features Frame-level Multiplexing and out-of-order frame reassembly for maximum link utilization.
  • End-to-end data protection with hardware parity, CRC, ECC and other advanced error checking and correcting ensure that data is safe from corruption.
  • Detailed real-time event logging and tracing enables quick diagnosis of SAN problems.
  • Universal Boot capability allows the appropriate boot environment to be automatically selected for any given OS.
  • Strong authentication between host and fabric is based on Fibre Channel Security Protocol (FC-SP) Diffie-Helmann Challenge Handshake Authentication Protocol (DH-CHAP).
