Spdif Digital Optical Audio Matrix 4x2
1.Four ways of optical fiber signal input split or to Four sets of SPDIF signal receiving device.
2.Audio format support : DTS-HD/Dolby-trueHD/LPCM2.0/DTS/Dolby-AC3/DSD
3.Support signal retiming
4.Used optical fiber cable loss less the 0.2Db/m, Output distance is up to 40m.
5.The input control can through R/M and also can directly press the button.
6.Support last time working state memory when power off.
7.Over-voltage protection can prevent the damage caused by connecting unmatched power adapter to the machine, if the light for standby indication flashed, it shows that the output voltage from the power adaptor is too high and the adaptor needs to be changed. 8.LED status indication, it can tell us the working state of the device very easily.
9.No loss of quality
10.Installs in minutes
11.Need DC5V/1A power supply
Introduction :
This SPDIF/TOSLINK Digital Optical Audio 4x2 Matrix allows you to share 4 distinct audio inputs between 2 independent amplifiers or speakers. Providing convenient front push-button and remote control, the matrix switch allows every two input to be switched individually, meaning that every two different input sources can be shown on different output equipment, or a single source could be output to two, offering maximum flexibility.
Features:
* The machine shares 4 distinct audio inputs between 2 independent output devices
* Audio format support: LPCM2.0/DTS/Dolby-AC3
* Support signal retiming
* The output transmission distance is up to 40m when using optical fiber cable that losses less than 0.2dB/m
* Switched by remote control or front push-button
* Support last time working state memory when power off
* Over-voltage protection can prevent the damage from connecting unmatched power adapter to the machine, if the light for standby indication flashed, it shows that the output voltage from the power adapter is too high and the power adapter needs to be changed.
* The matrix features a LCD display for easy status monitoring
* No loss of quality
* Installs in minutes
Specification:
Supported Analog Audio Output audio format |
LPCM2.0/DTS/Dolby-AC3 |
Peak Wavelength |
650nm |
Max Baud Rate |
16Mbps |
Output Cable Distance |
≤40m(Use the optical fiber cable that losses less than 0.2dB/m) |
Max Working Current |
100mA |
Operating Temperature Range |
(0 to 40℃) |
Operating Humidity Range |
5 to 90%RH(No condensation) |
Power Supply |
5V DC |
Power Supply Cert |
CE,FCC |
AC Power Adapter |
US standard,UK standard and so on |
Package Content:
1) Main unit NO. 1 Sender2) Main unit NO. 2 Receiver
3) User Manual
Packing:
1. Bubble package, save shipping cost
2) Neutral gift box, beautiful in appearance.
3. OEM design package
