China supplier IR control SPDIF/TOSLINK digital audio mixer digital optical audio 4x2 matrix for micro ribbon cable
1.0 Introduction
This SPDIF/TOSLINK Digital Optical Audio 4x2 Matrix allows you to share 4 distinct audio inputs between 2 independent amplifiers or speakers. Providing convenient front push-button and remote control, the matrix switch allows every two input to be switched individually, meaning that every two different input sources can be shown on different output equipment, or a single source could be output to two, offering maximum flexibility.
2.0 Features
* The machine shares 4 distinct audio inputs between 2 independent output devices
* Audio format support: LPCM2.0/DTS/Dolby-AC3
* Support signal retiming
* The output transmission distance is up to 40m when using optical fiber cable that losses less than 0.2dB/m
* Switched by remote control or front push-button
* Support last time working state memory when power off
* Over-voltage protection can prevent the damage from connecting unmatched power adapter to the machine, if the light for standby indication flashed, it shows that the output voltage from the power adapter is too high and the power adapter needs to be changed.
* The matrix features a LCD display for easy status monitoring
* No loss of quality
* Installs in minutes
3.0 Specifications
Supported Analog Audio Output audio format |
LPCM2.0/DTS/Dolby-AC3 |
Peak Wavelength |
650nm |
Max Baud Rate |
16Mbps |
Output Cable Distance |
≤40m(Use the optical fiber cable that losses less than 0.2dB/m) |
Max Working Current |
100mA |
Operating Temperature Range |
(0 to 40℃) |
Operating Humidity Range |
5 to 90%RH(No condensation) |
Power Supply |
5V DC |
Power Supply Cert |
CE,FCC |
AC Power Adapter |
US standard,UK standard and so on |
4.0 Package & Shipping Contents
1) Main unit
2) DC 5V power supply
3) User Manual
