optical coaxial digital audio converter with R/L audio
Specification:
| Product Name | optical coaxial digital audio converter |
Model NO. |
PETDASM |
Input Audio |
Coaxial or Toslink digital audio |
Output Audio |
L/R audio or 3.5mm |
Input audio connector |
Toslink,1XRCA(Coaxial) |
Output audio connector |
2XRCA(R/L),3.5mm |
Sampling rate |
32, 44.1, 48 and 96 KHz |
Size(L-W-H) |
56X53X21MM |
Weight (Net) |
63g |
Limited Warranty |
1 Year Parts and Labor |
Operating Temperature |
0 ℃ to +70℃ |
Operating Humidity |
10% to 85 % RH (no condensation) |
Storage Temperature |
-10℃ to +80℃ |
Storage Humidity |
5% to 90 % RH (no condensation) |
Power Consumption |
0.5 watts (max) |
Converter Unit |
FCC,CE |
AC Power Adapter |
USB Power Cable |
User Manual |
English Version |
Description
The optical coaxial digital audio converter is designed for either home or professional audio application.
It converts Toslink / SPDIF or Coaxial digital audio signal to analog L/R or 3.5mm audio;
it can support an external device such as an amplifier via standard RCA-style L/R jacks,
and a stereo headphone via its 3.5mm at the same time.
Diagram
Features
This Converter has many features that enable it to perform in a superior manner. Among those features you will find:
* Converts SPDIF Optical or Coaxial digital PCM audio input to analog stereo L/R RCA and 3.5mm Cable outputs simultaneously
* Supported sample rates including 32kHz 44.1kHz, 48kHz, 96kHz and 192kHz, up to 24-bit resolution
* Ultra low jitter and high fidelity design using new receiver & D/A converter chips
* Auto sensing input selection with priority given to SPDIF; disable / disconnect SPDIF input for coaxial Input application
Advantages
1) We are one member of HDMI Association, export to any country is legal .
2)Specialized in HDMI products manufacture more than 6 years, stronger research and development team
3) 0 Risk for clients.More overseas exhibitions (Hongkong,Americal,Brazil,Germany etc.) are convenient for testing our products
4) Most regular customers from U.S.A , Brazil, Europe countries, Russia, Australia
5) OEM, ODM service avaliable
6) Stronger aftersales (RMA) service as manufacture.
7) Certs : CE, FCC, RoHS, HDMI Power Adaptor
Package Content
1) Main unit
2) USB Power Cable
3) User Manual
