0.6mm thickness High quality CNC Plasma Metal Cutting Machine 1325
1. Features:
1. The light structure beam to ensure the good rigidity, light weight and low inertia.
2. Gantry type structure, Y axis adopts dual synchronous motors and dual drives and circle guide for XYZ axis (optional squeal linear guide) to ensure steady transmission, high precision.
3. For advertising solid light, groove metal panels and the metal bottom panel for cutting, accuracy cutting and good indicator. If equipped with the U.S Treasure plasma power can achieve lower limitation of the laser cutting machine.
4. Small cutting incision, clear, no dregs, avoiding the secondary finishing process.5. Suitable for iron and aluminum plates, Zinc plating, white iron plates, titanium plates and other metal plates processing.
6. High-NC System configuration, automatic ARC, stable performance.
7. Support Wentai, Beihang Haier, ARTCAM, Type3, software such as the standard G code path files also could be read by software conversion software such as AUTOCAD, DXF format. U disk exchange control system processing files, easy to operate.
8. Plasma power and the cutting torch are supply by domestic well-known brands manufacturer.
9. OEM is available as customer’s requirements for the machine size and system.
2. Parameters:
Working area |
1300×2500mm |
Power |
8.5KW |
Cutting thickness |
0.5mm-15mm |
Cutting speed |
0-8000mm/min |
Input voltage |
3-phase 380V |
Frequency of power |
50Hz |
Plasma Current |
40A 60A 100A |
Document transmission form |
USB interface |
Working form |
Untouched arc striking |
Optional Power Source |
Hypertherm, Cut-Master |
Jinan Tian Jiao Machinery Manufacture Co., Ltd. specializes in developing and manufacturing Mechanical CNC routers, CNC Laser machines, Plasma cutting machines, cutting plotters and other machines. We provide global market with high quality CNC equipment. We are a leading company in this field, being confident in offering the best service and best quality.
With many years' hard work and perfect management system, we have classified our products into several categories: woodworking machines, advertising machines, ATC machines, stone working machines, plasma cutting machines, laser machines and plotters. We can also customize products and offer OEM service. Our products have been exported to many overseas countries, gaining good comments.
We hope to be your good, long-term and honest partner. Wish you can get joy and satisfaction from our products and service.
Q1: How to choose a suitable machine?
You can tell us the working piece material, size, and the request of machine function. We can
recommend the most suitable machine according to our experience.
Q2: This is the first time I buy the machine, is it easy to operate?
We can provide the operation manual or video for guiding. If it is hard for you learning, we can
also help you by “Team viewer”online, with telephone or Skype explain.
Q3: Can you customize the machine for me?
Yes, we provide customized solution, but considering the cost, we will recommend the
standard configuration to you first.
Q4: What is the guarantee? In case the machine break down?
The machine has 1 year guarantee, fail parts will be replaced for free if the machine under
“ normal operation”.
Q5: How about the documents after shipment?
We will send all the documents by air after shipment. Including packing list, commercial
invoice, B/L, and other certificates required by clients.
Q6: Delivery time?
For standard machine, it would be 7-10 working days; for non-standard machine, it would be
20 - 30 working days.
Q7: How is the payment?
Normally we accept T/T or L/C, if you like other terms, tell us in advance.
Q8: Do you arrange the shipment for me?
For FOB or CIF price, we will arrange shipment for you, for EXW price, you should arrange
the shipment by yourself.
Q9: How is the packing?
Step1: water proof wrapping film with foam protection in each corner.
Step2: Solid seaworthy wood box package with steel belt.
Step3: Save space as much as possible for container loading.
- One year machine warranty ,during the warranty period , if any parts broken,
we change a new part for you freely.
- All machines are debugged before shipment.
- Lifetime technical support and service.
- 24 hours on line or phone or by email technical support.
- We offer detailed machine manual, software manual, controller manual.
- Our factory make a vivid traing CD.
- Maintenance free of charge during lifespan.
- Free training course at our plant.
- Welcome to visit our factory, learn machine face to face.
