2016 hot sale table moving cnc router cutting acrylic plastic
1. Picture:
Application:
Mini-word. Hypotenuse word processing
Acrylic lettering sign making industries and aluminum products industry
Plastic and solid wood processing industry
Application material:
Wood. Acrylic, Aluminum, Copper etc.
Wood and acrylic can cut 2cm once.
Aluminum can cur 1cm
Configuration and Parameter
Model |
TJ-M1325AT |
Effective tracel range |
1300*2500*300mm |
Max processing size |
1300*2500mm |
Table size |
1300*2500mm |
Fast speed |
30m/min |
Max working speed |
15m/min |
Repeatability Accuracy |
±0.05mm |
Spindle |
China 9KW ATC spindle |
Cooling way for spindle |
air cooling |
Control system |
Syntec control system |
Driving system |
Japan Yaskawa servo motor and driver |
Orbit |
Imported PMI linear orbit |
Transmission way |
XYZ TBI ballscrew |
Tool magazine capacity |
8 tools |
Tool magazine type |
Linear type |
Vacuum pump |
With |
Working voltage |
AC380V/3PH/50HZ |
Machine size |
|
Packing size |
|
Feature:
1.This is a strength type of machining center. It adopt linear type tool mafazine with 8 bits,
and the tool change only need 10 seconds.
2. Function extensive; such as carving and milling, cutting, side milling etc. This machine
can be suitable for processing diversified and compound products.
3. The machine adopt imported 9KW ATC spindle, Japan Yaskawa servo motor and drive
sustem. Schneider electric components, Delta inverter and some other imported or joint
venture machine parts. Stable performance and low failure rate.
4. Vacuum table. It’s very convenient to loading and unloading of workpiece,.
5. Table moving, make sure stable moving, high precision, and cutting surface more smooth
Samples:
Video:
