Mini Router Cnc for Sale
- Qingdao
- Money Gram Credit Card
You May Like
-
Mini Cnc Metal Milling Machine 3020 for Sale
-
Advertising Mini Desktop Cnc Router With TJ-6090
-
Advertising System, Advertising Cnc Router With TJ-6090
-
2 Heads Cnc Router Machine From Shandong for Metal Label 1212
-
Woodworking/Advertising/Metal/Stone CNC Engraver Machine Cnc Router for Advertising 1200 X1800 mm
-
6090 Reading USB Memory Directly Mini CNC Router Bits for Wood
Product Details
| Condition | New | CNC or Not | CNC | |
| Place of Origin | Shandong, China | Brand Name | Tianjiao | |
| Model Number | TJ3020 | Voltage | 220V | |
| Power(W) | 1.5KW | Dimension(L*W*H) | 880*670*530mm | |
| Weight | 200kg | Certification | CE | |
| Warranty | 1 year | After-sales Service Provided | Engineers available to service machinery overseas |
Product Description
mini router cnc for sale
Features:
1.thick cast iron
2.Y axis square orbit,X Z axises round orbit, ballscrew
3.Nc-studio control system
4.800W imported bearings water cooling spindle
Main technical parameter:
Machined surface:single/double
Worktable board:300*200mm
Max. speed: 8000mm/min
Working speed: 0-4000mm/min
Working accuracy: 6 - 8mil
Least line diameter and least line spacing: 6 - 8mil
Drilling depth: 0.02 ~ 3mm
Drilling diameter: 0.4 ~ 3.175mm
Drilling holes: 40-100/min
Repeat Accuracy: 0.025mm
The least error of Data control drill less than 1mil (0.015mm)
Operation system: WIN2000/XP /VISTA
Means of communication: PCI
Function Request: Protel PCB document can be directly put in. (gerber)
Spindle speed: 24000rpm
Spindle power: 800W
Power supply: AC210-240V
Volume: 1000*1000*1200mm
Gross Weight: 200Kg
Standard Configurations | Options |
Lathe Bed with aluminium cast table | iron cast table |
Three axis with imported round guides and double ball screw nuts |
|
NCSTUDIO system | DSP handle |
800wwater cooling spindle | 1.5KW/2.2KW water cooling |
Leadshine driver | Yako |
Technical Data | |
X Y Working Area | 300mm*200mm |
Z Working Area | 120mm |
Table Size | 450mm*450mm |
Max. Speed | 4m-5m/min |
Max. Working Speed | 2m-3m/min |
Working Delicacy | 0.025mm |
Repositioning Accuracy | 0.05mm |
Feeding Height | >100mm |
Command Code | G Code*.u00*.mmg*.plt |
Working Software | Windows98/2000/xp |
Power (not including spindle) | 300w |
Working Voltage | AC220V/50HZ |
Spindle Power | 800w |
Spindle Running Speed | 0-24000rpm |
Motor | Stepper |
Photos:
Video link:
samples:
Before sale
1.Patient introduce and professional suggest buying selection
2.Real time report production situation
3.Take pictures and make videoes with your done machine
4. Strict test and debugg machine quality before shipping
After sale
24 hours on line service and phone on
2 years gurantee term
During gurantee term, repair or change damaged parts for free
Exceed gurantee term, offer at cost price
Manager: Isabella
skype: xihong61
Trademanager: cn209782924
qq: 2417071086
Phone: 86 15866646109
Jinan Tian Jiao Machinery Manufacture Co.,Ltd. is specialized in developing and manufacturing Mechanical CNC router (woodworking router, advertising router, stone engraving router), CNC Laser machine, Plasma cutting machine, cutting plotters, metal mould engraving machine and other cnc machines. We supply global market the high quality CNC equipments. We are leading company in this field and being confident in offerring the best service and best quality.
