Thread Making Machine
US$ 3,000 - 13,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Application:
fastener
Production Capacity:
3m/min
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Condition
New
Application
fastener
Production Capacity
3m/min
Place of Origin
Hebei, China
Brand Name
Xinggong
Model Number
z28-80
Voltage
380v
Power(W)
4kw
Dimension(L*W*H)
1480*1330*1440mm
Weight
1700KG
Certification
ISO9001, CE, ISO9001:2000
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Thread Making Machine
This machine is widely praised for its rational price, easy maintenance, produced well, high quality by customers. Besides axial and radial process, this machine can be used to process regular and irregular bolt, through screw with optional embossing roller. In Zhejiang Standard Parts Base, China, the through screw made with this machine has been exported to US, Canada and Europe.
Parameters:
| Max. rolling pressure | 150KN |
| Working diameter | 4-42mm |
| OD of roller | 120-170mm |
| BD of roller | 54mm |
| Max. roller width | 100mm |
| Dip angle of main shaft | +-5degree |
| Center distance of main shaft | 120-240mm |
| Rotary speed of main shaft | 36 47 60 78 |
| Feed speed of main shaft | 5mm/s |
| Thread length | no limit |
|
Main power
|
4kw |
| Hydraulic power | 2.2kw |
| Weight | 1700kg |
| Size | 1480*1330*1440mm |
