Specifications
small shotcrete pump:1.hydraulic driven system;
2.Pump the wet concrete to 150m;
3.Double-piston with S-tube valve
high quality wet-mix shotcrete pump
RISEN RPB7 shotcrete pump can be used for the conveying and spraying of wet-mix concrete. Typical applications include permanent and temporatry rock support in tunnels and mines, or in fact wherever sprayed concrete is to be applied. It can also for pumping, grouting, repaire work, artificial soil seeding, mortar spraying, and refractory material spraying. Being a piston pump it provides much more versatility, in both mix types and potential conveying distances, than a rotor/stator pup of a similar capacity. Pumping of thick and stiff mixes also poses no problem, as the concrete is delivered up to 67bar. Its compact design enables easy intergration into any kinds of carrier chasssis.
Technical data:
Parameter |
Unit |
Value |
Output |
m 3/h |
7 |
Pressure |
MPa |
5 |
Hopper capacity |
L |
170 |
Loading Height |
mm |
1050 |
Suitable slump |
cm |
6-18 |
Max.grain size for spraying |
mm |
15 |
Pipe and hose size |
mm |
65/50 |
Horizontal converying distance |
m |
120 |
Vertical converying distance |
m |
50 |
Drop out |
% |
<8 |
Electric motor |
kW |
15 |
Air pressure |
MPa |
0.3 |
Use air value |
m3/min |
3 |
Dimensions |
mm |
2530×1300×1300 |
Weight |
kg |
1100 |
We are Manufacture and Supplier with more than 15 years, we can do better more!!!
