RISEN RISEN PZ Series Dry Mix Shotcrete Machine
PZSeries Shotcrete Machine:Shotcrete process is to use compressed air to convey the pre-dampened mix through delivery hose to the nozzle to project the material onto the sprayed surface under high velocity, and then to form concrete support layer after the projected material coagulates and hardens. With simple technology, special effect, economy cost, flexibility and high construction efficiency, shotcrete technology has widely been applying in construction, railway and super highway engineering, underground engineering, tunneling, mining operations, hydropower projects and slope stabilization, etc. and showing prosperous future.
· Non-adhesion going-through rotor with new material chamber, completely eliminate bonding and blocking during operation so as to reduce clearance and maintenance period.
· Thin flow conveying method with vortex flow, so the spraying flow is even, continuous and steady, to improve the shotcrete quality
· Four-point clamping device make it easy to adjust the press between sealing plate and rotor disk so as to no air and dusk leak and prolong consumption parts life
Model option instruction:
PZ- 1) 2) 3)
1) Rated Output Capacity: 3--3m3/h, 5--5m3/h, 9--9m3/h
2) Driven type: E--Electric motor, A--Air motor, D--Diesel Engine
3) Function: S--Single function type, M--Multi-function type.
Note:
1. For the Electric motor type and Single function type, the suffix-letter E and S can be omitted.
2. Comparing with Normal type, Multi-function type can realize the stepless speed regulation of output capacity from 0 to Rated value, Auto-lubrication of Rubber friction pairs to increase the using life and other indicating functions.
Technology descriptionCE Certificate
Item |
PZ-3 |
PZ-5 |
PZ-9 |
Output |
PZ-3: 3m3/h |
PZ-3: 3m3/h |
PZ-3: 3m3/h |
PZ-3M: 0-3m3/h |
PZ-5M: 0-3m3/h |
PZ-5M: 0-3m3/h |
|
Max. conv.dist |
200m |
200m |
150m |
Water cement ratio |
0.4 |
0.4 |
0.35 |
Max.Aggregate.size |
10mm |
10mm |
10mm |
Hose inner diameter |
42mm |
50mm |
64mm |
Operating air pressure |
0.2-0.6MPa |
0.2-0.6MPa |
0.2-0.6MPa |
Air consumption |
PZ-3:5-6m3/min |
PZ-5:7-8m3/min |
PZ-5:9-10m3/min |
PZ-3A: 10-11m3/min |
PZ-5A: 15-16m3/min |
PZ-5A: 19-20m3/min |
|
Power |
PZ-3: 4kW |
PZ-5: 5.5kW |
PZ-5: 7.5kW |
PZ-3D: 10hp |
PZ-5D: 10hp |
PZ-5D: 22hp |
|
Weight |
PZ-3: 430kg |
PZ-5: 720kg |
PZ-9: 900kg |
PZ-3D: 680kg |
PZ-5D: 950kg |
PZ-9D: 1050kg |
|
PZ-3M: 500kg |
PZ-5M: 850kg |
PZ-9M: 950kg |
|
Dimenssion(LxWxH) |
PZ-3: 1.1x0.6x1m |
PZ-5: 1.3x0.8x1.2m |
PZ-9: 1.5x0.9x1.3m |
PZ-3D: 2x1x1.1m |
PZ-5D: 2.2x1x1.3m |
PZ-9D: 2.6x1x1.3m |
|
PZ-3M: 1.5x1x1.1m |
PZ-5M: 1.8x1x1.1m |
PZ-9M: 1.8x1x1.2m |
CE Certificate
