High Efficiency Grouting Pump

Name: High Efficiency Grouting Pump
Brand: RISEN
SKU: 124323919

US$ 1,000 - 9,000 MOQ: 1 Set

Key Specifications

Place of Origin:

Henan, China

Brand Name:

RISEN

Model Number:

RG130/20

Risen Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin shanghai qingdao port

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Henan, China

Brand Name RISEN

Model Number RG130/20

Specifications

high efficiency grouting pump
1.single cylinder, double action
2.realiable
pact structure
4.aluminum casing

The RISEN RG130/20 is a single piston double-acting grouting pump with gear reducer, which is a universal medium-pressure grouting pump.

----The basic version is electric motor, and optional version is diesel engine.

Technical data:

Item	RG130-20	RG60-40
Work elements	single cylinder double action. spherical valve reversing	single cylinder double action. spherical valve reversing
Output	130 L/min	60 L/min
Pressure	2 Mpa(20bar/290psi)	4 Mpa(40bar/580psi)
Cylinder Dia	φ75 mm	φ75 mm
Piston stroke	85 mm	85 mm
Piston Speed	180 /min	85 /min
Inlet diameter	51 mm	38 mm
Outlet diameter	38 mm	32 mm
Power unit	5.5 kW(Electric) 10hp(Diesel)	5.5 kW(Electric) 10hp(Diesel)
Transmission	V-belts +gear case	V-belts +gear case
Chassis	Skid	Skid
Weight	260 kg	210 kg
Dimensions	1400×650×920 mm	1280×485×645 mm
Note:Single or Double Passageway.Skid or Tyre

Application:

Grouting single slurry in tunnels, slope, mines, bridge and all sorts of underground engineering etc.;
Repairing engineering with grouting.

Features:

Single piston double-acting
Gear&vee belt transmission makes this pump high mechanical efficiency and working
reliability
Integrated valve house and ball valve, together with compact structure
Body of pump is made of aluminum casting,low weight is an advantage for transport
