Commodity: H.F. welded steel tube mill For HG273
Technical Flow:
Uncoiling - Flattening-Shearing&butt welding-Strip Accumulating-Forming-High-frequency induction welding-Bead and burr removing-Zinc patching -Cooling-Sizing Inside Removing-UltrasonicTesting-Cutting-Checking &Collecting-Binding-Weighing-Marking-Accessing Warehouse
Specifications
1.Product Specifications
I. Round pipe diameter range: Φ114mm-273mm
wall thickness :3mm-10mm
II. Square and rectangle tube : 89*89mm-200*200mm
wall thickness range 3-10mm
III .Tube and pipe length: 6-12m
2. Material Specifications:
Low carbon steel and low alloy steel:
δb≤550Mpa
δs≤235Mpa
3. Line specification
production speed:0-40m/min
Line Direction: right to left(from operator' s side), or by customer's requirement
