Help Center76mm Cold Roll Forming Mill
Related Products
Specifications
76mm carbon steel tube mill:1.Pipe OD: 32mm-76mm
2.Thickness: 1.5mm-4mm
3.Material:Carbon steel and low alloy
Commodity: 76mm cold roll forming Mill
I. Brief introduction:
76mm cold roll forming Mill is designed to produce welded pipes of 32mm-76mm in OD and 1.5mm-4mm in wall thickness,as well as corresponding square and rectangle tube.
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 32mm-76mm Thickness: 1.5mm-4mm
Square tube: 25mm×25mm 60mm×60mm, Thickness: 1.5mm-3mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80
3. Tube mill
Production Speed :20-65 m/min
Direction : left to right or right to left from operator`s side decided by customers.
III. The technical flow of the production line
Uncoiling→Shear & butt welding→Cage looping (Accumulating)→Forming →HFwelding→Removing & outsied Bead →Cooling→Sizing→Cutting off→Conveying →Downloading → Packing →Warehousing
IV. Makeup of tube mill line
1. Double-reel Mechanical Uncoiler
2. Shear & Butt Welder
3. Cage Loop(Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. NC Flying Saw
7. Output Rollway
8. Rollers
