Help Center377mm ERW Steel Tube Mill
Related Products
Specifications
Commodity: ERW steel tube mill1. OD:165mm-377mm
2. Thickness: 4mm-12.7mm
Commodity: ERW steel tube mill
377mm welded pipe production line is designed to produce welded pipes of 165mm-377mm in OD and 4mm-12.7mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 165mm-377mm Thickness: 4mm-12.7mm
Square & rectangle tube: 130mm*130mm-300mm*300mm, Thickness: 4.0mm-10mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: HR & CR Carbon steel coil(GB Q195∼Q345 / API∼X80)
3. Tube mill
Production Speed : 10-40 m/min
III. The technical flow of the production line
IV. Makeup of tube mill line
1. Double-reel Mechanical Uncoiler
2. Shear & Butt Welder
3. Cage Loop (Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. NC Flying Saw
7. Output Rollway
8. Rollers
