406mm ERW Welded Steel Pipe Making Machinery

406mm ERW Welded Steel Pipe Making Machinery thumbnail-1
406mm ERW Welded Steel Pipe Making Machinery photo-1
US$ 4,444 - 77,777 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Other, Pipe Production Line, HG406
Pipe Material:
Carbon Steel
Application:
Drain Pipe
Contact Supplier Request Quote Chat Now
Shijiazhuang Zhongtai Pipe Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Xingang
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Other, Pipe Production Line, HG406
Pipe Material Carbon Steel
Application Drain Pipe
Place of Origin Hebei, China
Brand Name ZTZG, ZTZG Zhongtai
Model Number HG406

Specifications

406mm pipe making machinery is designed to produce welded pipes of 165mm-406mm in OD and 5mm-16mm in wall thickness
.

Commodity: pipe making machinery



406mm welded pipe production line is designed to produce welded pipes of 165mm-406mm in OD and 5mm-16mm in wall thickness, as well as corresponding square and rectangle tube.



II. Basic Technical Information:

1.Specification of pipes

Pipe OD: 165mm-406mm                  Thickness: 5mm-16mm

Square & rectangle tube: 150mm*150mm-320mm*320mm,

Thickness: 5.0mm-13mm

Length: 6 -12m                         Length Tolerance:  ±3mm

2.Raw Material:

Material: HR & CR Carbon steel coil(GB Q195∼Q345 / API∼X80)

3. Tube mill

Production Speed : 10-40 m/min



III. The technical flow of the production line

Uncoiling→Flattening→Shearing & Butt welding→Cage looping (Accumulating)→Strip →Trimming→Forming→HFwelding→Removing burrs (inside & outside)→IF annealing→Air & Water cooling→Sizing→Pipe UT→Cutting off→Flattening test→End facing→Hydrostatic test→Conveying →Downloading →Appearance→MarkingPacking →Warehousing



IV. Makeup of tube mill line

1. Double-reel Mechanical Uncoiler

2. Shear & Butt Welder

3. Cage Loop (Accumulator)

4. Tube mill

5. Solid State H.F. welder

6. NC Flying Saw

7. Output Rollway

8. Rollers

 .
