Help CenterHG610 Pipe Making Machines
Related Products
Specifications
Commodity:HG610 Pipe making machinespipe of OD 219-610mm&corresponding rectangle and square tube
Thickness:6-19mm
Commodity |
HG610 Pipe making machines |
Round Pipe Size(mm) |
219mm - 610mm |
Pipe Thickness (mm) |
6mm-19mm |
Square Pipe Size(mm) |
Max Square Tube: 480×480mm Max Rectangle Tube 600×360mm |
Pipe Thickness (mm) |
4mm-14 mm |
Material |
Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80 |
Pipe Length(m) |
6 -12m |
Length Tolerance(mm) |
±3mm |
Line Direction |
right or left(from operator's side) |
Production Speed(m/min) |
Max 40 m/min |
|
|
Technical Flow |
Coil Feeding→Uncoiling→Flattening→butt welding→Accumulating→Side Trimming→Forming→High-frequency induction welding→Removing outside & inner Bead →Polishing→Online UT → Seam Annealing→Cooling→Sizing→Cutting into length →Conveyer Table→Straightening→End Facing and beveling→Hydro Testing→Inspection→Packing→Warehouse
|
|
Tube Bottom Pass line/ Line Power/ Electricity Input Power etc. |
Belong to confidential information and detail parameters will be known in the quotation list. |
