ERW HF Straight Welded Pipe Mill Line

ERW HF Straight Welded Pipe Mill Line thumbnail-1
ERW HF Straight Welded Pipe Mill Line photo-1
US$ 200,000 - 300,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Type:
Pipe Production Line
Pipe Material:
Carbon Steel
Application:
Drain Pipe
Contact Supplier Request Quote Chat Now
Shijiazhuang Zhongtai Pipe Technology Development Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Tianjin Port
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Pipe Production Line
Pipe Material Carbon Steel
Application Drain Pipe
Place of Origin Hebei, China
Brand Name ZTZG
Model Number HG50

Commodity: HF straight welded pipe mill line



I. Brief introduction:

50mm welded pipe production line is designed to produce welded pipes of 20mm-50mm in OD and 0.8mm-2.0mm in wall thickness, as well as corresponding square and rectangle tube.



II. Basic Technical Information:

1.Specification of pipes

Pipe OD: 20mm-50mm                  Thickness: 0.8mm-3.0mm

Square tube: 20mm×20mm 40mm×40mm, Thickness: 0.8mm-2.0mm

Length: 6 -12m                         Length Tolerance: ±3mm

2.Raw Material:

Material: Carbon steel coil(GB Q195-Q345); Alloy steel coil; API 5L X42-X80

3. Tube mill

Production Speed : 20-80 m/min

Direction: left to right or right to left from operator`s side decided by customers.



III. The technical flow of the production line

Uncoiling→Shear & butt welding→Cage looping (Accumulating)→Forming →HFwelding→Removing & outsied Bead →Cooling→Sizing→Cutting off→Conveying →Downloading → Packing →Warehousing



IV. Makeup of tube mill line

1. Double-reel Mechanical Uncoiler

2. Shear & Butt Welder

3. Cage Loop(Accumulator)

4. Tube mill

5. Solid State H.F. welder

6. NC Flying Saw

7. Output Rollway

8. Roller
