Help CenterStraight Welded Steel Pipe Machine for ERW660
Related Products
Specifications
pipe making machine for ERW6601 Pipe OD:325-660mm
2 Thickness:6~20.0mm
3 Voltage: 380V; 50Hz
Commodity: pipe making machine for ERW660
I. Brief introduce:
ERW660mm welded pipe production line is designed to produce welded pipes of 325mm-660mm in OD and 6.0mm-20.0mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
Specification | |
Round Pipe |
O.D:325~660mm |
Thickness:6.0~20.0mm | |
Square&Rectangular pipe |
255*255-520*520mm |
Thickness: 6.0~19.0mm | |
Length |
Length: 6 -12m Length Tolerance: ±3mm |
2.Raw Material: Low carbon steel and low alloy steel:
δb≤500Mpa δs≤235Mpa
3. Tube mill
Production Speed : Max 20m/min
III. The technical flow of the production line
IV. Makeup of tube mill line
1. Uncoiler
2. Shear & Butt Welder
3. Cage Loop (Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. NC Flying Saw
7. Output Roll way
8. Rollers
Remark:
To protect confidential information, Here only show basic parameters. Detailed parameter will be
known in the quotation list or negotiate with customer.
