Specifications
ERW273 tubes metal forming1. Pipe OD:89mm-273mm
2. Thickness:3mm-10mm
Commodity:ERW273 tubes metal forming
273mm welded pipe production line is designed to produce welded pipes of 89mm-273mm in OD and 3mm-10mm in wall thickness, as well as corresponding square and rectangle tube.
II. Basic Technical Information:
1.Specification of pipes
Pipe OD: 89mm-273mm Thickness: 3mm-10mm
Square & rectangle tube: 70mm*70mm-200mm*200mm, Thickness: 3.0mm-8.0mm
Length: 6 -12m Length Tolerance: ±3mm
2.Raw Material:
Material: HR & CR Carbon steel coil(GB Q195∼Q345 / API∼X80)
3. Tube mill
Production Speed : 10-40 m/min
Direction : left to right or right to left from operator`s side decided by customers.
III. The technical flow of the production line
Uncoiling→Shear & butt welding→Cage looping (Accumulating)→Forming →HFwelding→Removing & outsied Bead →Cooling→Sizing→Cutting off→Conveying →
Downloading → Packing →Warehousing
IV. Makeup of tube mill line
1. Double-reel Mechanical Uncoiler
2. Shear & Butt Welder
3. Cage Loop(Accumulator)
4. Tube mill
5. Solid State H.F. welder
6. CNC Flying Saw
7. Output Rollway
8. Rollers
