Single Cylinder GX390 Gasoline Engine Welding Generator
| NAME | ITEM | SHW190 | SHW210R | SHW300E | |||
| Engine | Engine Model | GX390 | GX670 | ||||
| Type | 4-stroke, OHV, 1 cylinder | 4-stroke, OHV, 2 cylinders | |||||
| Displacement(cc) | 389 | 670 | |||||
| Bore*Stroke(mm) | 88*64 | 77*72 | |||||
| Cooling system | Air cooling | ||||||
| Ignition system | Transistorized magneto ignition | ||||||
| Start system | Recoil/Electric | Electric | |||||
| Generator | Rated voltage(V) | 220(AC) | 220(DC) | ||||
| Rated frequency(HZ) | 50/60 | 60 | |||||
| Rated current | 9.1A(AC) | 15A(AC) | 10.0A(DC) | ||||
| Rated output 50HZ | 2.5KVA(AC) | 5.0KVA(AC) | 5KW(DC) | ||||
| Rated output 60HZ | 3.0KVA(AC) | 5.0KVA(AC) | |||||
| Rated power factor | cos =1.0 | ||||||
| Phase | Single | ||||||
| Type | 2-pole, rotating type | 24-pole, rotating type | |||||
| DC Welder | Rated Max. current(A) | 180 | 200 | 300 | |||
| Load voltage(V) | 27.2 | 28 | 32 | ||||
| Current range(A) | 50-180 | 60-190 | 60-300 | ||||
| Max. current duty cycle(percent) | 50 | 32 | 20 | ||||
| Applicable welding rod diameter(mm) | 2.5-5.0 | 2.5-5.0 | 2.5-6.0 | ||||
| Rated Revolving Speed(r/min) | 3600 | ||||||
| No-load voltage(A) | 70 | 52 | 82 | ||||
| Idle control | Automatic | ||||||
| Rectifier type | Six phase half wave rectifier | Three phase full wave rectifier | |||||
| Other | Fuel tank capacity(L) | 13 | 27.5 | 23 | |||
| Length*Width*Height(mm) | 690*510*520 | 690*535*540 | 953*617*622 | ||||
| Net weight(kg) | 86 | 88 | 180 | ||||
