Gasoline Engine(AD168F)

Name: Gasoline Engine(AD168F)
Brand: ANDITIGER,ANDI ,ELEFUJI ,ELEMAX,ASTRA KOREA
SKU: 124271353

Negotiable MOQ: 100 Sets (Price negotiable depending on order volume and customization)

Key Specifications

Usage:

Other, Automobile&Boat

Fuel:

Gasoline

Stroke:

4 Stroke

Taizhou Longfa Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Ningbo Port

Delivery Detail:

Delivery time depends on order quantity.

Usage Other, Automobile&Boat

Fuel Gasoline

Stroke 4 Stroke

Cylinder Single Cylinder

Cold Style Other, Air-cooled

Start Other, Electric start/Kick start

Place of Origin Zhejiang, China

Brand Name ANDITIGER,ANDI ,ELEFUJI ,ELEMAX,ASTRA KOREA

Model Number AD168FE

Specifications

1.High quality power output
2.Qualified mechnical seal device
3.Compact in structure and convenient for carry

Engine

•With Strict Testing from Spare Parts to whole Machine,ANDITIGER have superior durability with high performance -price ratio,it is

number one Silent engine

•Large fuel tank capacity ,four hours of continuous operation

•High quality power output

•Qualified mechanical seal device

•Compact in structure and convenient for carry

•Easy starting by recoil or E-start(key start with battery)

•Special balancer shaft inside reduces the vibration to the minimum level

ENGINE (GASOLINE ENGINE)Specification

NAME	ITEM	AD168F	AD168F-1	AD170F	AD173F	AD188F	AD190F
Gasoline Engine	Engine Type	Air-cooled,4-stroke,OHV;single cylinder
	Bore Stroke(mm)	68×45	68×54	70×54	73×58	88×64	90×66
	Displacement(cc)	163	196	210	242	389	420
	Compression Ratio	8.5:1	8.5:1	8.5:1	8.2:1	8.0:1	8.0:1
	Max.Power Output(KW)	(5.5HP)4.1	(6.5HP)4.8	(7.0HP)5.1	(8HP)5.9	(13HP)9.6	(15HP)11
	Rated Power Output(KW)	(4.0HP)3.0	(5.8HP)4.3	(6.0HP)4.4	(7.2HP)5.3	(11.7HP)8.6	(13HP)9.6
	Max.Torque(N.m)	10.8	13.2	14	16.7	26.5	28
	Ignition System	Transistor magneto
	Start system	Recoil/Electric
	Engine Oil Capacity(L)	0.6	0.6	0.6	1.1	1.1	1.1
	Fuel Capacity(L)	3.6	3.6	3.6	6.5	6.5	6.5
	Min.Consumption of Fuel(g/kw.h)	360	360	360	325	325	325
	Power Take Off	Crankshaft or Camshaft
	Crankshaft Direction	Left
	Dimensions(LWH)(mm)	390×330×350	390×330×350	390×330×350	515×420×470	515×420×490	515×420×490
	Net Weight(kg)	16	16	15	25	31	31
	Air cleaner	Semi-dry;Oil bath;Dual
