Portable Digital Inverter Generator(AD2200-B)

FOB Price

USD $170 - $180 / Set

100 Sets(Min.Order)

Product Details

Place of Origin:	Zhejiang, China	Brand Name:	ANDI,ANDITIGER,ELEMAX ,ASTRA KOREA ,ELEFUJI	Model Number:	AD2200-B
Output Type:	DC	Speed:	3600/rpm	Frequency:	50/60HZ
Rated Power:	1kw	Rated Voltage:	220V	Rated Current:	4.5A

1.high quality ,from the appearance to the inside ,spare parts
2.steady performance,low noise
3.long consecutive working time

Application

Household/outdoor power supply,your mobile power station.

Features and Technical parameters

1. 2.4hp Engine

2.recoil start

3.stable quality carburetor

4.best quality crank case

5,muffler with low noise

6. four stroke,single crock,air -cooled

NAME	ITEM	AD1200	AD2200
Engine	Type	Force air-cooled,1-cylinder,4-stroke,OHV
	Displacement(cc)	53	105
	Rated power output(kw/rpm)	1.2/5000	1.7/5000
	Max.power output(kw/rpm)	1.4/5500	2.2/5500
	Bore Stroke(mm)	43.5×35.8	52.4×57.8
	Ignition system	T.D.I
	Starting system	Recoil starting
	Fuel tank capacity(L)	2.7	4
	Fuel consumption(g/kw.h)	420	400
	Continuous operating hour(70% of rated load)	6
	Noise(7m away)(dba)	58	70
Generator	Rated output frequency(HZ)	50/60
	Rated output voltage(v)	110/120/230/240
	D.C.Output(V)	12/8.3A
	A.C.Oupput(V)	110/120/230/240
	Rated power output(KVA)	0.9	1.7
	Max.power output(KVA)	1	2
Dimension	Product size:(LWH)(M)	470×255×400	525×290×420
	Net weight(kg)	13	20
	Packing size(mm)	480×260×410 (color box)	540×305×435
Standard Features	Fuel indicator,Auto voltage adjustor,Oil alert system,Circuit breaker without fuse,Circuit protector,Paralled connection box,Digital display control panel
