Industrial Standby Generator Super Silent Diesel Generator 25kva Diesel Generator Price
◊ Features
1. Hand start(recoil) or Electric start with battery
2. Silent cart type /open type is optional
3.Copper/ Aluminium Alternator is optional
4. High quality Muffler /Silencer with low noise
5. Low Oil pressure alarm system
6. With/Without ATS system is optional
7. Single-phase or three -phase is optional
8. Strong carton packing, inside with foam
◊ Technical data
1. Rating output power can be up to 100 KVA
2. Phase :3-phase
3.Start system :Electric start with battery
4. Net Weight: 985 kg
| ITEM | 10-100KVA DIESEL SILENT GENERATOR | |||||||
| Rated frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Rated output(kVA) | 10.6/13.1 | 17/20 | 24/28 | 28/35 | 37/45 | 50/60 | 62/75 | 80/100 |
| Max.output(kVA) | 11.6/14.5 | 18.5/22 | 26/30 | 31/38 | 40/48 | 54/64 | 66/80 | 85/105 |
| Rated Voltage(V) | 400/230 | 230/400 | 230/400 | 230/400 | 230/400 | 230/400 | 230/400 | 230/400 |
| 416/240 | 240/416 | 240/416 | 240/416 | 240/416 | 240/416 | 240/416 | 240/416 | |
| Rated current(A) | 15.3/18.2 | 24.5/27.8 | 34.6/38.9 | 40.4/48.6 | 53.4/62.5 | 72.2/83.3 | 89.5/104 | 115/138.8 |
| Rated speed(r/min) | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 | 1500/1800 |
| Pole No. | 4 | |||||||
| Loop mode | Signle-phase,three-loop | |||||||
| Excitation mode | Brushless self-excitation and constant voltage(AVR) | |||||||
| Power factor(cos) | 0.8(lag) | |||||||
| Insulation grade | H | |||||||
| Engine model | KD388G | KD488G | KM493G | KM493ZG | KD4105G | KD4105ZG | KD6105G | KD6105ZG |
| Engine type | Two/Three-cylinda | Four-cylinda | Six-cylinda | |||||
| in-lined,four-stroke,direct injection,water-cooled | ||||||||
| BoreXStroke(mm) | 88X90 | 88X90 | 93X102 | 93X102 | 105X125 | 105X125 | 105X125 | 105X125 |
| Total displacement(L) | 1.642 | 2.19 | 2.771 | 2.771 | 4.33 | 4.33 | 6.494 | 6.494 |
| Compression ratio | 18.2:1 | 18.2:1 | 18.2:1 | 18.2:1 | 17.5:1 | 17.5:1 | 17.5:1 | 17.5:1 |
| Cooling water capacity(engine)(L) | 1.87 | 6 | 10 | 3.9 | 5.1 | 30 | 45 | 45 |
| Radiator tank(L) | 3.25 | 3.7 | 8 | 8 | 10.4 | 10.4 | 12 | 12 |
| Lube oil capacity(L) | 6.9 | 8.5 | 8.5 | 8.5 | 11 | 11 | 18.5 | 18.5 |
| Starting system | 12V Electric starter | |||||||
| Fuel type | 0#(summer),-10#(winter),-35#(chillness)diesel | |||||||
| Fuel Consumption | ≤340 | ≤320 | ≤320 | ≤300 | ≤300 | ≤290 | ≤290 | ≤290 |
| Output voltage(V) | 400/230;416/240 | |||||||
| Receptacle | Two single-phase receptacles | |||||||
| Connection pole | Available | |||||||
| Noise level(zero load-full load)[dB(A)/7m] | 51/53 | |||||||
| Fuel tank capacity(L) | 65 | 65 | 95 | 95 | 95 | 95 | 110 | 110 |
| Continuous running time(h) | 15/12 | 10/8.5 | 10.5/9 | 9.5/7.5 | 7/6 | 5.5/4.5 | 5.5/4.5 | 4.5/4 |
| Overall dimension(LXWXH)(mm) | 1570X780X1050 | 1570X780X1050 | 1900X950X1200 | 1900X950X1200 | 2250X950X1300 | 2250X950X1300 | 2700X1140X1500 | 2700X1140X1500 |
| Dry weight(kg) | 685 | 720 | 960 | 985 | 1270 | 1310 | 1650 | 1680 |
TaizhouLongfa Machinery Co.,Ltd established in 2003,which is specialized in producing series of gasoline generator ,diesel generator,gasoline engine ,water pump and parts of generators .Meanwhile ,all of our machines have passed CCC,ISO9001/2000 and CE certificate.We devoted ourselves to offering both qualified products and satisfying service to our customers and strive continuously.
1.Q:What is the Quality Warranty for the products?
A:We offer 1 year quality warranty for all of our products.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, Zhejiang Province, China, about 2 hours train from Shanghai . All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:What is the material of your products?
A: Only New material can be used for our products.
Materials for Generator: 100% Pure Crankcase, 100% Pure Copper Wire
Materials for Water Pump: 100% Pure Auminium Pump body and Crankcase
4.Q:What is Minimum Order quantity?
A: MOQ 50/100 pieces for different products.
You are welcomed to consult for details.
5.Q:How does your factory do regarding quality control?
A: From the internal parts to the outside packing, we not only make standard quality test,but also think ahead for a better solution. Except company QC system, We have achieved CE & SONCAP certificate.
