Help CenterDiesel Power Generator Zambia Silent Diesel Generator Set 20KVA Silent Diesel Generator
Related Products
-
7kv Iso9001 Silent Diesel Generator SetUS$ 428 - 598MOQ: 10 Pieces -
Air Cooled 7000W Semi-silent RUSSIA 3 Phase Key Start Diesel GeneratorUS$ 369 - 399MOQ: 50 Sets
-
3000W Professional Open Type Electric Start Diesel Generator With WheelsUS$ 319 - 339MOQ: 100 Sets
-
6.5KW 7KVA KAMA Type Super Silent Portable Diesel Generator for SaleUS$ 485 - 600MOQ: 10 Sets
-
China Supplier 3000 Watts Air Cooled Electric Start 220 Volt Portable GeneratorUS$ 260 - 450MOQ: 100 Sets
| ITEM | DIESEL SILENT GENERATOR |
| Rated frequency(Hz) | 50/60 |
| Rated output(kVA) | 17/20 |
| Max.output(kVA) | 18.5/22 |
| Rated Voltage(V) | 230/400 |
| 240/416 | |
| Rated current(A) | 24.5/27.8 |
| Rated speed(r/min) | 1500/1800 |
| Pole No. | 4 |
| Loop mode | Signle-phase,three-loop |
| Excitation mode | Brushless self-excitation and constant voltage(AVR) |
| Power factor(cos) | 0.8(lag) |
| Insulation grade | H |
| Engine model | KD488G |
| Engine type | Four-cylinder |
| in-lined,four-stroke,direct injection,water-cooled | |
| BoreXStroke(mm) | 88X90 |
| Total displacement(L) | 2.19 |
| Compression ratio | 18.2:1 |
| Cooling water capacity(engine)(L) | 6 |
| Radiator tank(L) | 3.7 |
| Lube oil capacity(L) | 8.5 |
| Starting system | 12V Electric starter |
| Fuel type | 0#(summer),-10#(winter),-35#(chillness)diesel |
| Fuel Consumption | ≤320 |
| Output voltage(V) | 400/230;416/240 |
| Receptacle | Two single-phase receptacles |
| Connection pole | Available |
| Noise level(zero load-full load)[dB(A)/7m] | 51/53 |
| Fuel tank capacity(L) | 65 |
| Continuous running time(h) | 10/8.5 |
| Overall dimension(LXWXH)(mm) | 1570X780X1050 |
| Dry weight(kg) | 720 |
1.Q:What is the Quality Warranty for the products?
A:We offer 1 year quality warranty for all of our products.
2.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, Zhejiang Province, China, about 2 hours train from Shanghai . All our clients, from home or abroad, are warmly welcome to visit us!
3.Q:What is the material of your products?
A: Only New material can be used for our products.
Materials for Generator: 100% Pure Crankcase, 100% Pure Copper Wire
Materials for Water Pump: 100% Pure Auminium Pump body and Crankcase
4.Q:What is Minimum Order quantity?
A: MOQ 50/100 pieces for different products.
You are welcomed to consult for details.
5.Q:How does your factory do regarding quality control?
A: From the internal parts to the outside packing, we not only make standard quality test,but also think ahead for a better solution. Except company QC system, We have achieved CE & SONCAP certificate.
