3 jaw Vertical through-hole Hydraulic Power Lathe Chuck for CNC wheel vertical lathe machine

FOB Price

USD $829.51 - $2,105.22 / Set

1 Set(Min.Order)

Supply Ability 12628 Set / Sets per Month
Port SHANGHAI QINGDAO NINGBO TIANJIN DALIAN etc.
Payment Terms:T/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:	Jiangsu, China	Brand Name:	DRAKE	Model Number:	YK3-08''L
Power:	Hydraulic	Number of Jaws:	3

Product Description

3 jaw Vertical through-hole Hydraulic Power Lathe Chuck for CNC wheel vertical lathe machine

Product Description

Technical features:

1. Patent product, vertical type with baseboard.
2. Super thin body, easy retrofit.
3. Accuracy, within 0.03mm.
4. Pneumatic operation Standard.
5. This chuck is applicable for machining center, driller and miller.
6. 2 jaw and 4 jaware available.

7. Rigid and short construction makes the stationary 3 jaw chucks ideal for

operating in machining centers

Parameters

There are three questions to answer to aid the correct choice of power chuck:
1. Type and model of CNC lathe.
2. Length of workpiece?
3. Outer diameter of workpiece?
4. Processing requirement?

Size Parameters

Model/Spec	D	D1	d	L1	L2	L3	H	H1	h	p
YK3-04L"	115	160	-	2~15	120	-	116	92	20	14
YK3-05L"	135	175	20	2~15	140	-	120	97	26	14
YK3-06L"	172	218	35	2~17	180	-	142	109	26	20
YK3-08L"	208	265	40	2~17	220	-	155	115	26	25
YK3-10L"	252	310	60	2~20	260	-	157	115	26	30
YK3-12L"	322	400	80	2~20	340	150	185	133	30	30
YK3-15L"	400	480	100	2~20	430	150	220	148	35	43

It is recommended to grease chucks at least twice a day in order to maximize longevity

Performance Parameters

Model/Spec	Jaw Stroke (Diameter) (mm)	Max. static clamping force (kgf)	Max. static holding force (kgf)	Permissible pressure (Mpa)	Clamping range	Holding range	Net Weight (kg)
YK3-04L"	3.2	2440	1630	0.4-1.5	3-115	15-120	8
YK3-05L"	3.7	3060	2040	0.4-1.5	5-130	15-140	11
YK3-06L"	4.2	5300	3460	0.4-1.5	5-170	20-180	18
YK3-08L"	5	8360	5100	0.4-1.5	10-210	25-230	28
YK3-10L"	6.5	11520	7140	0.4-1.5	20-250	30-260	40
YK3-12L"	8.5	13660	9990	0.4-1.0	30-320	40-340	75
YK3-15L"	12	19890	13260	0.4-1.0	40-400	60-420	120

Certifications

Work Flow & Packing

Equipments

Video

3 jaw Vertical through-hole Hydraulic Power Lathe Chuck for CNC wheel vertical lathe machine 3 jaw Vertical through-hole Hydraulic Power Lathe Chuck for CNC wheel vertical lathe machine
