5000W hybrid solar wind system grid off

Specifications

5kw  off-grid wind  and solar hybrid system

Solar & wind hybrid systems product mainly use for home ,street lights system,both of them are Economic, Green and Environmentally Friendly .

At night or rainy day, wind turbine generate wind power. In sunny day, solar panel generate solar power. In windy and sunny day, both of them generate power.

wind turbine :3pcs or 5pcs blades optional; guy cable tower or free stand tower optional;

solar panel :mono or poly panel optional; battery capacity and quantity can be optional;

 Question: What can be included for this system?

Answer: This system includes:solar panels,wind turbine(wind generator+blades+tower),wind and solar hybrid controller,inverter,battery,solar pv cable,bracket,and disconnectors.

 Question: What's the advantage for this hybrid system?

 Answer: 1.Steady operating.

                  2.The most advantage:On grid energy backup(not means sell electricity,just backup)

                  3.Make the utmost of nature resource of wind and sun.

                  4.Easy installation according to our instructions.

                  fessional parts supply

 Question:  How about the lifetime?

 Answer: The life time for solar panel is 25years,wind turbine is 20years,another parts is from 6-15years

5KW Solar and Wind hybrid power system
PICTURE	MODEL	PACKING SIZE(MM)	WEIGHT(KG)	QTY(PCS)	Remarks
	2KW/96VDC Wind generator           [Permanent-magnet -3phase A.C. Aluminum Alloy material]	1660*520*360mm	172 KGS	1	Notes: 1.pictures shown are for reference; 2.power consumption data is based on areas with average wind speed of 4.5m/s and average daily peak power sunshine of 4hrs. 3.the battery capacity is designed for 2 days backup in non-sunshine and windless weather lar panel racks and cables are not included
	2KW/96VDC blades, 3pcs[4.0m reinforced FPR,(blade),(wheel hub & press board), (dome)]
	Guy cable tower[Height 6m,Galvanized seamless steel pipe surface, then spray antiseptic white paint]	3000*89*89mm	60 KGS	1
	200W/36V Mono solar panel	1598*838*88mm/CTN, 2pcs/ctn	33KGS/CTN(2pcs/ctn)	15
	5KW/96VDC off-grid solar inverter (LCD display,indoor,DC input 96V,AC output 220V/50HZ ,without the lightning protection,can be made with AC section)	555*345*530mm/CTN	35 KGS	1
	5KW/96VDC Wind and solar hybrid controller	master device package size: 500*300*300mm, dump load box package size: 750*450*260mm	master device weight: 9kgs, dump-load box weight: 19.5kgs	1
	12V200AH Gel battery(green shell)	522*240*218mm/CTN	64 KGS/PC	8
