Solar System 10kw for Home Use, Building, Office, Hotel, Industry...

Off grid solar power supply system- GT-10KW

System

Basic Information

Solar panel rated output power: 10KW

Suitable for daily power consumption : <32KWH

Allowable max loads power : 12KW

Solar panel

Type: polycrystalline or mono solar panel

Max power :200w

Vmp:36.8V

Imp :8.3A

Size : 1498*998*40mm

25 years power output guarantee

(CE TUV)

QTY

50pcs

PV Array Combiner

Simplify wiring between PV array

and controller, protections

to controller ,features:

Wide range of DC input voltage

Reliable thunderstorm& surge protection

Multiple PV strings inputs

Service time :10 years,

QTY

2pcs

Notes:

1.pictures show are for reference.

2.power output data is based on areas with daily average peak power shine of 4.5hrs

3.the battery capacity is designed for power storage of 1.5-2 days PV output

lar panel rack can be specially designed based on site condition

Remark:

1)solar panel have 3 years warranty;

2)other parts have 2 years warranty;

3)ship the free parts for service(best service in china)

4)accept OEM

Controller

Model:96V80A

PWM charging mode intelligent control.,

temperature compensation,

various protection functions;

QTY

1pc

Inverter

Pure sine wave inverter;10kw

DC input:96v

Output 110V/220v (optional)

Use copper transformer;

Bypass function with AC charger;

Protection against short-circuit, over load, high-voltage and low-voltage protection

QTY

1pc

Battery

Capacity;12V/200AH

Solar power lead-acid battery, full sealed

Service life:5-6 years ,warranty :2 year

QTY

40pcs

Solar panel rack

Flat –roof type mounting rack ,

No welding/ cutting at site,

easy mounting.

More options to select:

Slope-roof mounting rack

Array type rack ;Standing –pole type rack

QTY

1set

Cables

International standard, with specification suitable for solar system,

200m
