P5 SMD waterproof full color led display screen with iron case
| Item | Parameter | |||
| Pixel Pitch | 5mm | |||
| LED Encapsulation | SMD 3030/1R1G1B | |||
| LED Chips | Epistar | |||
| Module resolution | 32dots*32dots | |||
| Module size(mm*mm) | 160mm*160mm | |||
| Pixel density | 40000dots/m² | |||
| Weight | 0.56KG | |||
| Drive chip | 2026 | |||
| Drive Method: | 1/8scanning | |||
| Brand of power supply | CL 5V~40A | |||
| Gray Scale | Recommended 256 level | |||
| The best viewing angle | Horizontal:140 Vertical:90 | |||
| Max Power Consumption | 1200W/ m² | |||
| Control Mode | Video frequency synchronization | |||
| Optimal Viewing Distance | ≥10m | |||
| Brightness | ≥7000cd/m² | |||
| Blind Spot Rate | <0.0001 | |||
| Brightness Control | 0-255 Grade | |||
| Contrast | 100 levels adjustable | |||
| Earth Leakage Current | <2mA | |||
| MTBF | >5000Hours | |||
| Lifespan | >100000Hours | |||
| Power Supply Mode | AC220V/50HZ or AC110V/60HZ | |||
| Protection Level | IP65 | |||
| Humidity | 0%~90% | |||
| Operating System | Windows98/me/2000/NT/XP | |||
| Operating temperture | Operation:-30°C~+60°C |
|||
Can you visit our factory in china?
Our factory is open to our customers , warmly welcomed you to visit us ,and the person who is responsible will guide you to scan the workshop every step, you will know the rough producing situation, then you will trust us . Business is long time cooperation. Trust is the most important between each other . I think we can not only do business together ,but also can be good friends. The future is belong to both of you and us .
What are the differences between the outdoor ,indoor, semi-outdoor LED display ?
1:Brightness: the brightness of indoor LED displays are much less than the outdoor and the semi-outdoor LED display. The brightness Of outdoor LED display and the semi-outdoor LED display are closed.
2:waterproof level: indoor and semi-outdoor LED display are not waterproof.
What a led display can show exactly?
1. Video play: It can play various signals, such as TV, DVD,VCD. It can also switch to different videos at any time, and zoom or cut video operation.
2. Word processing: It can display various character with different fronts, types and character information, it also may roll up the pages, shift, rotate, snow flow, screen rolling, glint and more than other 10 types display functions.
3. Picture display: It can play various graphics, pictures, such as BMP ,JPG ,GIF ,TIFF ,TXT ,DOC,PPT format etc.
4. Cartoon demonstration: It can play two or three cartoons, and revivify the vivid effect of the picture
5. Random layout: The powerful software can play video images, characters, graphics independently, tile up the characters information and cartoons etc.
