Specifications Indoor Fulll Color P2.5 Led panel Display
p2.5 indoor led video display
1.High refresh ratio
2.High brightness utilization
3.highly cost effective
4.low power cost
Detail Specifications of Indoor Full Color P2.5 LED panel display
| Model No. | P2.5 |
| Pixel Pitch | 2.5mm |
| Module Size | 160*80mm |
| Pixel Density | 160000 |
| Pixel composition | 1R1G1B |
| Module Resolution | 64*32 |
| The Optimum Viewing Distance | 2~12m |
| The Optimum Viewing Angle | H:120° V:120° |
| Maximum PowerConsumption | 600W/m2 |
| Standard Cabinet Size | 640mm*640mm |
| Cabinet Weight | 30Kg |
| Driving Method | 1/16 Scan |
| Frame Frequency | ≥60Hz |
| Refresh Rate | ≥180Hz |
| White Balance Luminance(CDm2) | ≥1000CD/m2 |
| Operating Environment Temperature | between -20°C and 60°C |
| Operating Voltage | 220V±10% |
| Grey Scale | Display Colors≥65.7trillion color(Synchronized) |
| Brightness Adjustment | 1024 grades of each color(R.G.B)can be adjusted manually and 16 levels of each color can be adjusted automatically |
| Input Signal | RF,S-Video,RSBHV,YUV,YC,COMPOSITION |
| Control System | PC+DVI display card+master card + optical fiber transmission |
| Average No Failure | ≥1000 hours |
| Time Life-span | >100000 hours |
| Out-of Control rate | <0.0002 |
| Transmitting Distance | Internet cable:<100m |
Advantanges ofindoor full color p2.5 led panel display
- High resolution of indoor full color LED display
- Integrated encapsulation is blessed with higher reliability
- Good color mixture from far or very near distance
- Good color consistency transparent picture
- Good picture uniformity
- Wide viewing angle
- Higher contrast ratio
- The most economical and rational solution for 3 in 1 full color technology.
Our Survice
1.Your inquiry related to our products or price will be replied in 12hrs.
2.OEM&ODM,any your customized lightings we can help you to design and put into product.
3.Distributoership are offered for your unique design and some our current models.
4.Protection of your sales area,ideas of design and all your private information.
5.Best cost performance and perfect service before and after sales.
6. Top Quality+Reasonable Price+Responsible After Service=Successful & Win
FAQ
How to protect power supply?
Electrical peaks can put more force on the electrical components which will decrease life time .
it is wise to install a protection (voltage stabilizer) that can control the peaks.
What is the life time for a LED module?
The life time for the LED screen is basically over 100,000 hours, but it depends how the client is taking care of his LED screen
and how it is used. When a LED Display´ life time gets to 100,000 hours, it means that the brightness of the LED lamps of theLED screen is about 50% off as compared to the original brightness depending on several factors that will enlarge a LEDscreen´s life time or reach 100,000 hours
How about the quality guarantee of your products?
We have manufacturing indoor advertising small led display screen for many years and can claim to produce a high quality that no competitor has yet succeeded in producing at the price quoted. The price we quoted leaves us with only the smallest of margins. They are in fact lower than those of our competitors for goods of similar quality.
What is your warranty?
One year
Picture Show
