Indoor P4 Full Color LED Screen
Part Number |
HERO-IDS4F-8S |
Resolution |
32(H)×32(V) |
Pixel Pitch |
4mm |
LED Configuration |
1R1G1B 3-IN-1 SMD |
Pixel Density |
62,500 pixels/ m2 |
Module Size |
128*128mm |
Driving IC |
MBI5024 |
Driving Method |
1/8 Scan, Constant Current |
Cabinet Weight |
42kg/sq.m. |
Mechanical Ratings | |
Hanging Weight Support |
2T |
Surface Flatness |
Gap<0.5mm |
Optical Ratings | |
Brightness |
>2,600cd/m2 |
View Angle |
150°/150° |
Gray Scale |
8bits input, correction with 14bits |
Display COLOR |
16.7M |
Brightness Adjustment |
0~100% |
Power Supply | |
Operation Power |
90~260V 50~60Hz |
Max. Power Consumption |
850W/m2 |
Average Power Consumption |
280W/m2 |
Control System | |
Control Mode |
Synchronous display with control PC by DVI |
Frame Update Frequency |
60~85Hz |
Screen Refresh Frequency |
300~1000Hz |
Gamma Correction |
-5.0~+5.0 |
Support Input |
Composite, S-Video, Component, VGA, DVI, HDMI, HD_SDI |
Control Distance |
Ethernet cable<120m or Fiber Optic<10Km |
Support VGA Mode |
1024×768, 1280×1024, 1600×1200, 1920×1280 |
Brightness Correction |
Pixel, Module, Cabinet |
Environmental | |
Operating Temperature |
-20°~+60° |
Operating Humidity |
10~95% RH |
Operating Life |
100,000hours |
MTBF |
5000hours |
Out of Control Rate |
<0.02% |
<0.02% |
|
Our Product
Guarantee and Service
(i) Warranty is for 2 years or optional
In the warranty period, If there is any quality problem caused by our side, you can send it back to us ,we will maintain and replace the defect components for free .
After 2 years, we only charge the material cost. If you prefer above 2 years warranty, you just pay 5% the amount of display per year.
(ii) Free training
You can send your engineers to our factory for one week training free of charge that include the software operation, installation, adjustment, basic repairing, etc.
(iii) Technical Support
If you need, we can send our engineer to guide the installation for you. But the relevant cost should be paid by your company, such as visa, hotel, food, both trip plane ticket, and so on.
FAQ
1. Can I visit your factory ?
We warmly welcome customers visit us. Before you come here, please kindly tell me your schedule, we can arrange for you. The nearest airport is Jinjiang airport, but there’re more airplane in Xiamen airport.
2. Can you provide me your catalogue?
We specialize in producing and developing all kinds of led displays. As a reliable LED Display manufacturer and exporter in China, we supply Indoor led displays, Outdoor led displays, semi-outdoor led displays.Please kindly tell me which kind of the item you prefer to and provide me more information. It will help us to give you a good price.
Besides the P10 outdoor full color LED display video, also include:
1. P3P4P5P6...indoor full color led display video;
2. P10/P12/P12.5/P16/P20/P25...outdoor full color led screen;
3. Indoor/outdoor/semi-outdoor single/dual color led panele
Thanks for your time, welcome to contact us for more informations.
Skype:Wanting Chen
Whatsapp:+8613226796065
