Help CenterSingle Crystal Sapphire Wafers
Related Products
-
Sapphire Windows/ Lenses for WatchUS$ 1 - 1MOQ: 10 Pieces -
Sapphire Windows/ Lenses for Mobile and CameraUS$ 1 - 1MOQ: 10 Pieces
-
Carriers (Mounts) for LD/PD Stents in Optical Communication DevicesUS$ 1 - 1MOQ: 1 Piece
-
SiC Crystal Wafers for Lense and WindowsUS$ 400 - 400MOQ: 10 Pieces
-
Aluminum Nitride Ceramic Substrates for High Power LD ModulesUS$ 5 - 5MOQ: 10 Pieces
The advantages of sapphire materials:
Sapphire single crystal, which is made up of single material Al2O3, has excellent properties. So right now it is widely used in optical instruments, LED and microelectronics substrates.
The properties of Sapphire
Material |
Density |
Crystal Structure |
Lattice Constant |
Mohs Hardness |
Melting Point |
Boiling Point |
α-Al2O3 |
3.95~4.1g/cc |
Hexagonal |
a=4.78Å, c=12.99Å |
9 |
2045oC |
3000oC |
TCE |
Specific Heat |
Thermal Conductivity |
Reflective Index |
dn/dt |
Light Transmittance |
Dielectric Constant |
5.8ppm/K |
0.418W.s/gK |
25.12W/mK |
n0=1.768, ne=1.76 |
13ppm/K @633nm |
~80% |
11.5//c, 9.3⊥c |
The specifications of the Sapphire wafers we provide:
Name: Sapphire Wafers
Materials: Single Crystal Sapphire, Al2O3
Size: 2 inches/ 3 inches/ 4 inches/ 5 inches/ 6 inches
Thickness: 0.43mm, 0.65mm, 1mm or customized
Tolerance: +/-0.1mm
Orientation: c-plane (0001)
Primary flat location: A-axis (11-20)+/-3o
Surface Roughness: Ra<0.3 nm
Edge chamfer: Rounded chamfer
Packaging and Global Express
5x24h Service
Focusing on the application of new energy & new materials fields, SunEnrich Technology Co., Ltd (SER), combined with Chinese Academy of Sciences (CAS), University of Science & Technology Beijing (USTB), China Iron & Steel Research Institute Group (CISRI), General Research Institute for Nonferrous Metals (GRINM), dedicate to the R&D and the application of rare metals (please check the pic. of SER’s materials). We have three manufactories located in Beijing, Shanxi Province and Guangdong Province. Beijing company is the R&D center; Shanxi company engages in rare metal materials; and Guangdong company is for the machining.
Our products are widely used in aerospace, semiconductor, medical equipment, automotive industry and other fields, the products are exported to Europe, America, Southeast Asia and Taiwan region.
1,Office Located in Chaoyang distract, Beijing
2,Sapphire Single Crystal & Machining Factory Located in Hebei (Share Holder)
3, Machining Factory located in Hebei (Shareholder)
Pl contact us:
Mr.Boris (Dirrect of marketing) ,+86-10-5773 8217
Ms.Du (QA) , +86-10-5773 8127
Doc.Zhang (CTO), +86-10-5773 8128
Mr.Cao ( supply chain management ), +86-10-5773 8129
