API 5CT N80 Oil Tubing /tubing N80/api 5ct P110 Steel Casing and Tubing
US$ 1,000 - 2,000
MOQ: 5 Tons
Key Specifications
Get Latest Price
Standard:
Grade:
Thickness:
4.24, 16
Payment & Shipping
Payment Methods:
Port of Shipment:
china main port
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
API 5CT P110 Seamless Carbon Steel Ape Tube Oil Casing PipeUS$ 1,000 - 2,000MOQ: 10 Tons -
OCTG API 5CT N80 7" Carbon Steel PipeUS$ 1,000 - 2,000MOQ: 1 Ton
-
ISO 11960 P110 Carbon Steel Well Oil Casing Tube From ChinaUS$ 500 - 1,000MOQ: 10 Tons
-
ISO 13680 API 5 CT P110 Oil Tubing China ManufacturerUS$ 1,000 - 2,000MOQ: 5 Tons
-
ISO 11960 C90 /API SPEC5CT Casing TubeUS$ 1,000 - 2,000MOQ: 1 Ton
Thickness
4.24, 16
Section Shape
Round
Outer Diameter
60.33 - 114.3 mm
Place of Origin
China
Secondary Or Not
Non-secondary
Application
Oil Pipe
Technique
Hot Rolled
Certification
API
Surface Treatment
Other, with paint
Special Pipe
API Pipe
Alloy Or Not
Non-alloy
API 5CT N80 oil tubing /tubing N80/api 5ct N80 steel casing and tubing
Standards: API Spec 5CT ISO13680
Uses:Tubing is used for extracting oil or gas from wells.
Dimension: OD 60.33-114.3mm WT 4.24-16mm
Grade: J55, K55, N80-1,N80-Q, L80-1, L80-9Cr,L80-1,C90, T95, C95, P110, Q125.
Tread types: NUE, EUE, VAM, STC, LTC, BTC, special clearance, XC,VAM TOP,NEW VAM.
Lengths:
| API 5CT Tubing | Range 1 | Range 2 | Range 3 |
| 6.10~7.32 | 8.53~9.75 | 11.58~12.80 |
Mechanical Properties : |
| Group | Grade | Type | Total elongation under load % | Yield strength Mpa | Tensile strength min MPa | Hardness max | ||
| min | max | HRC | HBW | |||||
| 1 | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 |
| 1 | J55 | - | 0.5 | 379 | 552 | 517 | - | - |
| K55 | - | 0.5 | 379 | 552 | 655 | - | - | |
| N80 | 1 | 0.5 | 552 | 758 | 689 | - | - | |
| N80 | Q | 0.5 | 552 | 758 | 689 | - | - | |
| 2 | L80 | 1 | 0.5 | 552 | 655 | 655 | 23 | 241 |
| L80 | 9Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | |
| L80 | 13Cr | 0.5 | 552 | 655 | 655 | 23 | 241 | |
| C90 | 1?2 | 0.5 | 621 | 724 | 689 | 25.4 | 255 | |
| C95 | - | 0.5 | 655 | 758 | 724 | - | - | |
| T95 | 1?2 | 0.5 | 655 | 758 | 724 | 25.4 | 255 | |
| 3 | P110 | - | 0.6 | 758 | 965 | 862 | - | - |
| 4 | Q125 | All | 0.65 | 862 | 1034 | 931 | - | - |
SIZE
