Automotive tubes-Fiberglass sleeving
- 1000000 Meter / Meters per Month
- Shenzhen
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | JDD TECH | |
| Model Number | MBQGD | Type | Other, Sleeve | |
| Material | Other, Fiberglass, Fiberglass |
Product Description
MBQGD is made of E-class fiberglass braiding sleeve treated at high temperature with a special kind of silicone resin and possess outstanding a temperature classification of 200℃. Usually it is used for the insulation protection for the wire harnesses in automotive field. It also has excellent properties of self-extinguishing and flexibility.
Application:
This sleeving is widely used for supplementary insulation on transformer, motor, generator and resistor etc.
Specifications:
Material: Fiberglass
Coating: Silicone resin
Working temperature: -60℃~+200℃
Breakdown voltage: 1.5kv~4kv
Flammability: UL VW-1
Color: White
Cutting tool: Cutting machine, scissor
Approval: RoHS, UL
Part No. | I.D. (I) | Tolerance | Wall thickness | Packing (L) | ||
1.5kv | 2.5kv | 4kv | ||||
MBQGD-1.0 | 1.0 | +0.3/-0.1 | 0.30±0.05 | 0.4±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-1.5 | 1.5 | +0.3/-0.1 | 0.30±0.05 | 0.4±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-2.0 | 2.0 | +0.3/-0.1 | 0.30±0.05 | 0.4±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-2.5 | 2.5 | +0.3/-0.1 | 0.30±0.05 | 0.4±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-3.0 | 3.0 | +0.3/-0.1 | 0.35±0.05 | 0.4±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-3.5 | 3.5 | +0.3/-0.1 | 0.35±0.05 | 0.45±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-4.0 | 4.0 | +0.3/-0.1 | 0.35±0.05 | 0.45±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-4.5 | 4.5 | +0.3/-0.1 | 0.4±0.05 | 0.45±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-5.0 | 5.0 | +0.4/-0.1 | 0.4±0.05 | 0.45±0.05 | 0.5±0.05 | 100 m/roll |
MBQGD-5.5 | 5.5 | +0.4/-0.1 | 0.4±0.05 | 0.45±0.05 | 0.6±0.05 | 100 m/roll |
MBQGD-6.0 | 6.0 | +0.4/-0.1 | 0.45±0.05 | 0.5±0.05 | 0.6±0.05 | 100 m/roll |
MBQGD-7.0 | 7.0 | +0.4/-0.1 | 0.45±0.05 | 0.5±0.05 | 0.6±0.05 | 100 m/roll |
MBQGD-8.0 | 8.0 | +0.4/-0.1 | 0.5±0.05 | 0.6±0.05 | 0.7±0.05 | 50 m/roll |
MBQGD-9.0 | 9.0 | +0.5/-0.1 | 0.5±0.05 | 0.6±0.05 | 0.7±0.05 | 50 m/roll |
MBQGD-10 | 10 | +0.5/-0.1 | 0.5±0.05 | 0.6±0.05 | 0.7±0.05 | 50 m/roll |
MBQGD-11 | 11 | +0.5/-0.1 | 0.5±0.05 | 0.6±0.05 | 0.7±0.05 | 50 m/roll |
MBQGD-12 | 12 | +0.5/-0.1 | 0.5±0.05 | 0.6±0.05 | 0.7±0.05 | 50 m/roll |
