K-B Chain Feeder Rotary Slotter

US$ 1 - 2 MOQ: 1 Set

Key Specifications

Get Latest Price

Type:

Slotter machine

Contact Supplier Request Quote Chat Now

Amc (Shanghai) Industrial Development Company Limited

Payment & Shipping

Payment Methods:

Port of Shipment:

China port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Type Slotter machine

Chain Feeder Rotary Slotter

Model: K-B

This machine can complete creasing, trimming, slotting and angle cutting of corrugated boxes at one time. Easy operation and high production efficiency.

Characteristics:

This machine can complete scoring, trimming, slotting and angle cutting of paper-board at one time in high efficiency.
Chain feeder for easy operation.
Electricslotting rotary position adjustment.
Synchronous manual adjustment for case height with hexangular stick.
Manual gap adjustment with worm reducer with graduated dial indication, ranging from 0 to 6mm.
Synchronous manual adjustment for slotting tools and creasers in lateral direction.
Zigzag slotting knife with 7mm thickness is made of alloy steel. It featuring with sharp edge and high hardness.
The punching device is available (additional option, not for free).

Specification:

Item	Unit	1200 series
Item	Unit	1200×2000	1200×2400	1200×2800
Max. machine speed	pcs/min	40/60	40/60	40/60
Max. feeding size	mm	1200×1900	1200×2300	1200×2700
Min. feeding size	mm	320×650	320×650	320×650
Slotting knife thickness	mm	7	7	7
Power required	KW	3	3	3
Machine Dimension	mm	2700×2550×1300	2700×3050×1340	2700×3350×1340

Item	Unit	1600 series
Item	Unit	1600×2400	1600×3000	1600×3500
Max. machine speed	pcs/min	40/60	40/60	40/60
Max. feeding size	mm	1600×2300	1600×2900	1600×3400
Min. feeding size	mm	400×650	400×650	400×650
Slotting knife thickness	mm	7	7	7
Power required	KW	3	4	4
Machine Dimension	mm	3320×3100×1340	3320×3600×1340	3320×4100×1340
