Power Max Dual Band CDMA PCS 850/1900MHz Mobile Amplifier

Name: Power Max Dual Band CDMA PCS 850/1900MHz Mobile Amplifier
Brand: Wiserepeater
Price: USD $302 - 316 / Piece

FOB Price

USD $302 - $316 / Piece

2 Pieces(Min.Order)

Supply Ability 1000 Piece / Pieces per Month
Port Shenzhen
Payment Terms:T/T Credit Card PayPal

Request Sample Customized Request Download Product Catalog

Contact Now

Get lowest price Inquiry Basket

Product Details

Place of Origin:

Guangdong, China

Brand Name:

Wiserepeater

Model Number:

WR8519L

Product Description

WiseRepeater System

Power Max Dual Band CDMA PCS 850/1900MHz Mobile Amplifier

What is Mobile Phone Repeater?

A mobile phone repeater picks up mobile phone signals from the outdoor antenna, then process and amplified the signal and rebroadcast to indoor areas by the indoor antenna. Mobile phone repeater is designed to increase mobile phone signal strength to all mobile phones on all mobile phone carriers and providers. Mobile phone repeater could virtually eliminate dropped calls, stuck text messages, and slow internet speed. Mobile phone repeater system is the one-time investment without extra fees or landline internet connection.

Repeater Description

Dual band CDMA PCS mobile repeater is a high powered repeater amplifier which boosts signal strength and coverage for all GSM/PCS voice networks for any US cellular services.

The power MAX 850/1900 is compatible with all GSM 850 and PCS 1900MHz services and guaranteed to provide improved coverage for your mobile phone signal over an area up to 1000 sqm.

Features:

a) CDMA 850 PCS 1900 Networks
b) 65 dB gain
c) Coverage up to 1000 sq ft
d) Supports 75 simultaneous users
e) Works with most US network providers
f) Simple and easy to install

Package includes:

1 x Power Max CDMA/PCS Repeater Amplifier
1 x Whip Antenna
1 x AC/DC main power supply

Specification

Technical Specification
Frequency	CDMA850: Uplink: 824-849MHz; Downlink: 869-904MHz PCS1900: Uplink: 1850-1910MHz; Downlink: 1930-1990MHz
Power	≥23 dBm
Gain	Uplink: ≥50dB; Downlink: ≥65dB
Coverage Area	1000 sqm
Connector Type	N-Female
Power Supply	DC12V 2A
Mechanical Specification
Color	Black
Dimension	194mm(L) x 234mm(W) x 30mm(H)
Net Weight	1620 gram
Operating Temperature	-10℃~60℃
Humidity	<90%

Installation

1) Typical Installation for Single Room

A. Find a tough spot which has strong signal reception to install your outdoor antenna.

B. Take your coaxial cable and connect it to the outdoor antenna.

C. Installing and Test the Mobile Repeater Unit

2) Multiple Rooms

To make signal coverage for multiple rooms, please refer to below diagram.

Please contact us for more guidance of mobile phone repeater installation.

Repeater FAQ

1) Q: Even the LEDs are green, my phone signal is still weak, why?
A: This usually caused by the weak signal at the outdoor antenna. Indoor signals boosting will be limited as a result of being not receive a proper signal at an outdoor antenna.
Try moving the outdoor antenna around to see if you can get a better signal. Ensured that the outdoor antenna is install correctly and tightly, also do not forget to check your coax cable for signs of damage.
Try to avoid installing the outdoor antenna in the areas with much woods and trees. It will stop it from receiving a proper signal.
If you have weak signal outside, you may need to get a high gain signal antenna to help you boost the signal.

2) Q: My signal goes up and down and calls drop, why?
A: This caused by oscillation. It means the signal from your outdoor antenna and indoor antenna are hitting each other and caused interference.
Try moving your outdoor and indoor antenna apart from each other, and they should be 10 meters away always.

3) Q: I can not get signals in some rooms, why?
A: This situation may happen when the building material blocks the signal from reaching the rooms, or your indoor antenna is too far away from your room.
Try moving you indoor antenna (basic unit) around to see if you can get it closer to the weak signal spot without affecting another week signal spot.
Or purchase a high basic unit, it can protect their signal through walls.
Or use one more indoor antenna.

Certifications

Safely import our CE RoHs FCC CCC certificated mobile phone repeaters

Shipping Service

Lead time is 1-2 days only. Worldwide shipping by DHL UPS FedEx TNT and other express companies. We do drop ship with the free handling charge.
