High quality ceramic polished silicon carbide plates
1.Pictures of Product
2.Feature of Product
1)Good properties of cauterization-resistance
2)Anti-oxygenation,anti-aging,anti-transfiguration
3)Heat-resistance and big intensity at high temperature
4)Perfect heat-conduction performance and wearability high quality silicon carbon plate
3.Parameter of Product
| Apparent porosity | ≤16% | |
| Bulk density | ≥2.65g/cm3 | |
| Cold compression strength | ≥100Mpa | |
| Modulus rapture at room temperature | ≥25Mpa | |
| Coefficient of thermal liner expansion | 4.5×10-6 /℃ | |
| Thermal conductivity | ≥12w/mk | |
| Refractoriness | 1600℃ | |
| 0.2Mpa (Loading softening point) | 1500℃ | |
| Max working temperature | 1400℃ | |
| Composition | SiC | ≥85% |
| Al2O3+SiO2 | ≤12% | |
| Fe2O3 | ≤1.0% | |
4.Producing Craft of Product
1)Reaction bonded silicon carbide plate, minimum thickness:8-10mm
2)Oxide bonded silicon carbide plate, minimum thickness:15-20mm
5.Application of Product
Shed board, flame clapboard and push board in the field of pottery porcelain and abrasive tool,etc.
More products details, pls click the photo.
