1600C electric industrial U/W type SiC heat element
- 10000 Piece / Pieces per Month
- Zhengzhou Qingdao Tianjin Bangalore/India SVX/Russia
- T/T Credit Card PayPal
- Heater Core Heater Welding Gun Heater Element
- Industrial Diesel Heater /Agricultural Vegetable Planting/Aquaculture Industry Heater
- Preheating equipment for hardbandig welding
- Heater Core Heater Welding Gun Heater Element
- DL-3 model electric air heater with upper outlet and lower inlet
- DL-2 model electric air heater with Left-Right Circulation
Product Details
Condition: | New | Type: | Other, electric heater | Power Source: | Electric |
Place of Origin: | Henan, China | Brand Name: | LEPE | Model Number: | LEPE-SiC-21 |
Weight: | 0.45kg | Voltage: | 220V | Power(W): | 1800W |
Product Description
1600C electrice industial U/W type SiC heat element
1) Non-metallic heating element, based on material of high quality green silicon carbide.
2) Compared with metal, SiC heating element is characterized by anti-oxidation, corrosion resistance, long service life, deformation, easy installation and maintenance.
3) Widely used in multiple high temperature furnace(magnetic material, powder metallurgy, ceramic, glass, metallurgy and mechanical used) and other electric heating devices
4) SiC heating element can be used in air atmosphere without any protect atmosphere.
Shapes: ED, GC, DB, U, W, UL, SC, SCR, UX
Diameter: 8mm, 10mm,12mm, 14mm, 16mm, 18mm, 20mm, 25mm,30mm,35mm, 40mm, 45mm, 50mm and so on.
Specific gravity | 2.6~2.8g/cm3 | Bend strength | >300kg |
Hardness | >9MOH’S | Tensile strength | >150kg/cm3 |
Porosity rate | <30% | Radiancy | 0.85 |
3. Technical parameter of rod type silicon carbide heating element
Diameter (OD, mm) | Hot zone (HZ, mm) | cold zone (CZ, mm) | Overall length (OL, mm) | Range of resistance (ohms) |
12 | 150-300 | 150-200 | 450-700 | 1.85-3.15 |
14 | 200-400 | 200-250 | 600-900 | 1.22-2.40 |
16 | 300-600 | 250-350 | 800-1100 | 1.60-3.00 |
20 | 300-900 | 300-400 | 1100-1500 | 1.14-3.10 |
25 | 300-1000 | 300-450 | 900-1600 | 0.75-2.40 |
30 | 400-1100 | 300-500 | 1000-1800 | 0.70-1.82 |
31.7 | 356-1499 | 280-406 | 916-2261 | 0.5-2.25 |
35 | 40-1700 | 300-400 | 1200-2300 | 0.68-2.89 |
38.1 | 406-1422 | 280-394 | 966-2210 | 0.4.-1.36 |
40 | 500-1700 | 300-400 | 1300-2300 | 0.60-2.02 |
44.4 | 508-2437 | 280-432 | 1068-3277 | 0.36-1.66 |
50 | 1000-2000 | 400 | 1800-2800 | 0.73-1.46 |
54 | 508-2438 | 305-458 | 862-3278 | 0.30-1.40 |
Standard export package: plywood box with expanded plastic and sponge
for more details, please press the picture
MoSi2 heating element
Tungsten copper alloy
Ceramic fiber board
Thermocouple
