Specifications
Insulation ceramic fiber hard board1.Temp:1000-1800C
2.Al2O3%:35-75
3.Standard: 900*600*(6-200)mm
4.Customizable
High rigidity and light weight insulation ceramic fiber hard board
Lepe ceramic fiber board is made of shattered cotton compressed together using inorganic adhesives by the wet vacuum suction filter process.With such advantages as low density and high intensity, the product has a wide range of applications, like as the hot surface of furnace lining to withstand the direct impact of flames and high-temperature gas glows.
High stability insulation ceramic fiber hard board
Low thermal conductivity
Low thermal capacity
Resistance to thermal shock
Resistance to erosion
Easy to be processed and cut
High thickness precision and size precision
Exceptional ability to withstand flames and gas flows
Easy to install and convenient to us
| Model | LEPE-1000 | LEPE-1260 | LEPE-1420 | LEPE-1600 | LEPE-1800 |
| Classification Temperature | 1000 ℃ | 1260 ℃ | 1420 ℃ | 1600 ℃ | 1800 ℃ |
| Density(kg/m3) | 280-600 | 280-600 | 280-600 | 280-600 | 280-600 |
| Reheating Linear Change |
(800°C×24h) <2 |
(1100°C×24h) <2 |
(1200°C×24h) <2 |
(1500°C×6h) <2 |
(1500°C×6h) <1 |
Al2O3 |
35 | 42 | 35 | 63.5 | 75 |
Al2O3+SiO2 |
>96 | >98 | 88.5 | >99 | >99.5 |
Fe2O3 |
0.2 | 0.2 | 0.2 | <0.1 | <0.1 |
ZrO2 |
8 |
Common specification: 900X600X (6-200) mm
Special specification: Tailored to specific customer drawings
Wrapping: wooden box with foam insulation ceramic fiber hard board
LEPE ceramic fiber board has great anti-mechanical-destruction capacity, and can be applied as materials which require tenacity, self supporting ability,and thermal insulation ability. More specifically, it can be used as : thermal insulation lining and back lining in pusher kilns, ladle furnaces, bell-cover kilns,tunnel kilns, roller kilns, and aluminum melting kilns, and thermal treatment furnaces; high-temperature fire damper board and thermal insulation for kiln cars; thermal insulation for various high-temperature industrial kilns and furnaces. insulation ceramic fiber hard board
