Home > Products > Ceramic Fiber Board > 1800C ceramic fiber insulation board as furnace liner
1800C ceramic fiber insulation board as furnace liner
- 10000 Piece / Pieces per Month
- FOB Zhengzhou/Qingdao/Shanghai CIF Singapore Seoul
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Thickness: | 6-200mm | Width: | 600mm | ||
Length: | 900mm | Grade: | HA (High Aluminum) | Chemical Composition: | Al2O3 |
Working Temperature: | 1700C | Place of Origin: | Henan, China | Model Number: | FB-13 |
Brand Name: | LEPE |
Product Description
1800C ceramic fiber insulation board as furnace liner
Characteristics of Ceramic Fiber Board
High stability
Low thermal conductivity
Low thermal capacity
Resistance to thermal shock
Resistance to erosion
Easy to be processed and cut
High thickness precision and size precision
Exceptional ability to withstand flames and gas flows
Easy to install and convenient to us
Ceramic Fiber Board specification and wrapping
Common specification: 900X600X (25-150) mm
Special specification: Tailored to specific customer drawings
Wrapping: wooden box with foam
Model | LEPE-1000 | LEPE-1260 | LEPE-1400 | LEPE-1600 | LEPE-1800 | |
Classification temperature | 1000°C | 1260°C | 1400°C | 1600°C | 1800°C | |
Density(kg/m3) | 300-700 | 300-700 | 300-700 | 300-700 | 300-700 | |
Reheating Linear Change (%) | (800°CX24h)<1 | (1050°CX24h)<1 | (1200°CX24h)<1 | (1500°CX24h)<1 | (1600°CX24h)<1 | |
Chemical Composition (%) | Al2O3 | 38 | 42 | 50 | 68 | 85 |
Al2O3+SiO2 | 96 | 98 | 99 | 99.5 | 99.8 | |
Fe2O3 | 0.2 | 0.2 | 0.2 | - | - |
LEPE fiber board has great anti-mechanical-destruction capacity, and can be applied as materials which require tenacity, self supporting ability, and thermal insulation ability. More specifically, it can be used as : thermal insulation lining and back lining in pusher kilns, ladle furnaces, bell-cover kilns, tunnel kilns, roller kilns, and aluminum melting kilns, and thermal treatment furnaces; high-temperature fire damper board and thermal insulation for kiln cars; thermal insulation for various high-temperature industrial kilns and furnaces.
Business Type:Manufacturer, Trading Company
Registration No.: 410102000058705
Main Products:MoSi2 heating element,SiC heating element,Ceramic fiber board,Silicon carbide products,Silicon nitride products
Location:Henan, China (Mainland)
Contact Us
- Zhengzhou Lepe Refractory Materials Co., Ltd.
- Contact nameXin Fu
- Phone86-371-86079675
- AddressXiliu Lake Street Zhengzhou,Henan
