High temperature furnace 6mm ceramic fiber board
1.Description of Product
Lepe ceramic fiber board is made of shattered cotton compressed together using inorganic adhesives by the wet vacuum suction filter process.With such advantages as low density and high intensity, the product has a wide range of applications, like as the hot surface of furnace lining to withstand the direct impact of flames and high-temperature gas glows.
2.Photo of Product
3.Feature of Product
Lepe ceramic fiber board is made of shattered cotton compressed together using inorganic adhesives by the wet vacuum suction filter process.With such advantages as low density and high intensity, the product has a wide range of applications, like as the hot surface of furnace lining to withstand the direct impact of flames and high-temperature gas glows.
- High stability
- Low thermal conductivity
- Low thermal capacity
- Resistance to thermal shock
- Resistance to erosion
- Easy to be processed and cut
- High thickness precision and size precision
- Exceptional ability to withstand flames and gas flows
- Easy to install and convenient to us 6mm ceramic fiber board
4.Thermal Conductivity of Product
5.Physical Data of Product
| Model | LEPE-1000 | LEPE-1260 | LEPE-1420 | LEPE-1600 | LEPE-1800 |
| Classification Temperature | 1000 ℃ | 1260 ℃ | 1420 ℃ | 1600 ℃ | 1800 ℃ |
| Density(kg/m3) | 280-600 | 280-600 | 280-600 | 280-600 | 280-600 |
| Reheating Linear Change |
(800°C×24h) <2 |
(1100°C×24h) <2 |
(1200°C×24h) <2 |
(1500°C×6h) <2 |
(1500°C×6h) <1 |
Al2O3 |
35 | 42 | 35 | 63.5 | 75 |
Al2O3+SiO2 |
>96 | >98 | 88.5 | >99 | >99.5 |
Fe2O3 |
0.2 | 0.2 | 0.2 | <0.1 | <0.1 |
ZrO2 |
8 |
6.Size&Package of Product
Common specification: 900X600X (6-200) mm
Special specification: Tailored to specific customer drawings
Wrapping: wooden box with foam
7.Application of Product 6mm ceramic fiber board
LEPE ceramic fiber board has great anti-mechanical-destruction capacity, and can be applied as materials which require tenacity, self supporting ability,and thermal insulation ability. More specifically, it can be used as : thermal insulation lining and back lining in pusher kilns, ladle furnaces, bell-cover kilns,tunnel kilns, roller kilns, and aluminum melting kilns, and thermal treatment furnaces; high-temperature fire damper board and thermal insulation for kiln cars; thermal insulation for various high-temperature industrial kilns and furnaces.
