LAY37 push button switch 12v voltage push button switch
Main technical parameters:
- Rated insulation voltage: 660V (AC 50Hz)
- Conventional thermal current: 10A
- Button utilization category rated operational voltage and rated operational current
- Protective class: IP55
- Button with lamp rated operational voltage and power see list5
Application condition:
Pollution degree: 3
- Type of installation: II
The maximum voltage |
660V |
heating current |
10A |
AC-15 |
Rated working voltaget |
660 220 380 |
110 36 |
|
Rated working current |
1.8 5 2.7 |
10 10 |
DC-13 |
Rated working voltaget |
440 110 220 |
48 24 |
|
Rated working current |
0.6 2 1 |
4 4 |
|
Contact resistance
|
≤50mΩ |
Insulation resistance
|
>10MO |
|
The common button likemushroom head
|
Push button with lamp
|
Knob |
Mechanical life |
1100x104 |
30x104 |
10x104 |
Electrical life |
60x104 |
20x104 |
10x104 |
