Specifications
1)no clearance process2)reasonable process design
3)Convenient operation and maintenance
My company researched and developed steel wool production line since 2001, so far, our company is the only enterprise that have the core technology of steel wool production line in china. This machine not only has filled the Chinese domestic blank on this field ,but also are sold to Africa, Southeast Asia and Middle East and have won favorable comments from general customers.
MKR-500G production line ,according to the same production line abroad ,we continuously improve the quality of machine, that performance of products will be more more excellent.In addition,the production line has many
advantages ,such as reasonable process design, Convenient operation and maintenance, energy-efficient, Environmentally friendly and high efficiency ,etc.
Especially in making knife holder, adopt unique "no clearance process."(knife holder clearance Less than 0.05mm), without replacement lifelong.( we have applied patents for the Process method),not only reduce the cost of consumption for blade, knife holders,but also Improve the product production and the quality of the products. Under the guarantee of raw materials, Can produce high quality of various specifications and types of copper cottonl.
Main technical parameters
1 Specification-MKR-500G
2 cutting stations for main machine- 4
3 knife holders of main machine-60 groups
4 the wheel diameter of main machine- Ø500MM
5 wheel winding-36 circles
6the most point of contact- 2160
7 Production capacity-2000 kg /8h(1-80 varieties as the standard)
8 raw material of steel wool-SGM Ø3.00MM.(meet the requitments of GB/T 17505—4)
9 installed capacity-132.5KW(explain-Main electric motor 90KW,50Hz.With vector frequency conversion governor)
10 The total weight of machine-16000kg
